Lockwood 202 Exterior Round Corner Plate - Male Symbol Outlined Engraving | Satin Stainless Steel
The Lockwood 202 Series Exterior Plate with Male Symbol Outlined Engraving is part of the distinguished Artefact range of round corner plate door furniture. This exterior plate features an outlined male symbol engraving (code A) with black gloss infill on a Satin Stainless Steel plate face - providing clear identification of male facilities.
The outlined infill engraving style produces a refined symbol appearance with a black gloss outline and hollow interior. No lever, cylinder or turn snib. Non-handed. Pairs back-to-back with the 203 Series interior plate (round corner).
Estimated Warehouse Dispatch
Usually ships in 11 business days
Usually ships in 11 business days
Special Order - Non-Returnable Item
Please confirm suitability before ordering.
Please confirm suitability before ordering.
Available Finish Options
Satin Stainless Steel
SS - Non-handed
Fire Rated
- Fire rated up to 2 hours - AS1905.1:2005. Fire performance is dependent on doorset type and configuration. Compliance is system-based and limited by the FRL of the complete doorset assembly.
Key Features
- Round corner 162 x 162mm exterior plate with 10mm radius corners - Lockwood Artefact 202 Series
- Plain Plate with Male Symbol Outlined Engraving (Function 07, code A)
- Outlined infill - black gloss outline with hollow symbol interior
- Non-handed. No lever, cylinder or turn snib. Concealed fixings at 4 points. Supplied in trade pack.
- Tested to Level D8 (500,000 cycles) - AS4145.2-2008. Fire rated to 2 hours - AS1905.1:2005
- 25-year mechanical warranty
Suitable Uses
- Male or men's bathroom, toilet and change room doors in commercial, institutional and public buildings
- Push/pull pass doors requiring male facility identification on the door furniture plate
- Architecturally specified projects requiring gender identification on a round corner stainless steel plate
Full Specifications
Dimensions & Technical Drawings
Plate dimension drawing - 162 x 162mm round corner profile, 10mm radius corners and cross-section details.
Standards and compliance - fire rating, Level D8 cycling test and anti-corrosion.
Functions diagram - full range of 202/203 Series plate configurations.
Part number builder and ordering procedure for the 200/202 Series.
Helpful Tips
- Outlined vs solid infill: Code A produces an outlined male symbol. For full solid infill in Natural Anodised Aluminium refer to 20207RNNT (code R).
- Matching sets: For a matched male/female set in Satin Stainless Steel, pair with the female symbol outlined variant (20207CNSS).
- Exterior plate - pairs with 203 Series: This is the outside face plate. It must be paired with a 203 Series interior plate (round corner) - not a 201 Series. The interior plate must use visible fixings.
- Thick doors: For doors 45-55mm, order long fixing screws SP2000-208 separately.
- Non-returnable: Confirm finish and handing before ordering - this item cannot be returned once purchased.
Lockwood Warranty (Australia)
Mechanical: 25 years. Electrical/electronic: 2 years (excl. batteries).
Mechanical: 25 years. Electrical/electronic: 2 years (excl. batteries).
Finish Warranty Guide:
- Everbrass: 25 years
- Stainless Steel, Chrome & Anodised: Up to 10 years
- PVD / VIVID: 10 years
- Symmetry: 5 years
- Decorative finishes (Bronze, Antique, Powdercoat): Typically 2 years
Cosmetic finishes, batteries, normal wear and tear, misuse, unauthorised modification, corrosion and labour or freight costs are excluded.
This warranty operates in addition to rights under the Australian Consumer Law.
