Lockwood EXI294-SIL Exidor Single Panic Bolt Silver
The Lockwood EXI294-SIL Exidor Single Panic Bolt Silver is a surface mounted push bar panic exit device designed for emergency egress on suitable single doors and selected double door applications. It is part of the Lockwood Exidor series, a panic hardware range used where fast exit from the inside is required during an emergency.
The EXI294-SIL is the Exidor 294 two point single panic bolt. It retracts the top and bottom bolts when the push bar is operated, with the bolts remaining retracted until they are automatically released when the door closes.
This model includes an automatic top trip, an easy clean floor socket and an anti-thrust device in the main body to help resist leverage of the shoot bolts from their sockets. It is commonly specified in Australian commercial, industrial and public access buildings where a robust panic bolt is required in Silver finish.
Fire Rated
- Successfully tested on fire door assemblies in accordance with Australian Standard AS1905.1-2015 for fire resistant doorsets.
- Fire rated for use on timber and steel doors where the complete fire door assembly is correctly specified and installed.
- Fire door suitability depends on the complete approved door assembly, including door type, frame, fixings, hardware and installation method.
Usually ships in 3 business days
Key Features
- Push bar activated panic bolt for emergency exit operation
- Two point top and bottom bolt arrangement for secure door fastening
- Designed for single doors and selected double door applications
- Surface mounted design for practical installation and servicing
- Non-handed design, suitable for left hand and right hand door configurations
- Automatic top trip helps release the bolt mechanism when the door closes
- Easy clean floor socket supports more practical floor maintenance around the bottom bolt point
- Anti-thrust device helps resist leverage of the top and bottom shoot bolts from their sockets
- Tested to 200,000 operating cycles for long-term mechanical performance
- Silver finish supplied as standard for this item code
Suitable Uses
- Single door emergency exit applications
- Both leaves of double doors with non-rebated meeting stiles where specified
- Second opening leaf of rebated double door sets where specified
- Commercial and public access buildings requiring panic exit hardware
- Timber and steel fire door assemblies where the complete assembly is correctly specified
- Industrial, education, healthcare, retail and back-of-house exit doors
Full Specifications
Frequently Asked Questions
Is the EXI294-SIL only for single doors?
No. It is a single panic bolt, but the installation instructions state it can be used on single doors, both leaves of double doors with non-rebated meeting stiles, and the second opening leaf of rebated double door sets where correctly specified.
Can this be used on fire doors?
Yes, the Exidor series is fire rated for use on timber and steel fire door assemblies where the full door assembly is correctly tested, specified and installed. Always confirm fire door approval for the complete door and hardware set.
Is the outside lever trim included?
No. External lever trim is an accessory and must be ordered separately where outside access is required. A suitable Euro profile half cylinder is also required for that trim and is not supplied as part of the panic device.
Additional Information
- The EXI294-SIL is commonly chosen where a two point panic bolt is required rather than a single point panic latch.
- A common specification mistake is choosing a panic bolt or panic latch before confirming whether the door set is single, rebated double or non-rebated double.
- For doors exceeding the standard 2440mm height, the extended top shoot tube accessory should be checked during specification.
- External access from the outside requires a compatible outside access device and cylinder arrangement. These should be matched to the site keying schedule.
- For fire door applications, through fixings or other project-specific fixing requirements may be needed depending on the door manufacturer and fire test approval.
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship for:
- Mechanical components: 25 years
- Electrical and electronic components: 2 years (excluding batteries)
Lockwood Panic Exit Devices Catalogue
Lockwood Panic Exit Devices Catalogue
Lockwood Warranty Overview
Lockwood branded products are covered by manufacturer warranties issued by ASSA ABLOY Australia Pty Ltd. Warranty periods vary depending on product type, mechanical components, electrical elements, and finish category.
This overview summarises the structure of Lockwood warranty coverage. Full terms, exclusions and claim procedures are set out in the official Lockwood Warranty document.
Warranty Periods Summary
Finish Coverage Guide
- Everbrass finishes: up to 25 years against corrosion, tarnishing and discolouration.
- Stainless steel, polished stainless steel, chrome plating and anodised finishes: typically up to 10 years.
- Decorative finishes including Antique Copper, Architectural Bronze, Oil Rubbed Bronze, Aged Brass, Polished Brass, Satin Brass and related variants: typically up to 2 years against corrosion.
- Unlacquered brass finishes will naturally age and change appearance over time. This is not considered a defect.
- Tea staining of stainless steel is not covered where cleaning and maintenance have not been followed.
What the Warranty Covers
- Defects in material and workmanship during the applicable warranty period.
- Assessment by ASSA ABLOY to determine repair, replacement with the same or closest equivalent product, or refund of purchase price.
Common Exclusions
- Normal wear and tear.
- Misuse, abuse, accidental damage or use outside published specifications.
- Improper maintenance or failure to follow care instructions.
- Unauthorised modification, repair or use of non-genuine parts.
- Exposure to corrosive environments including coastal air, salt spray, chemicals or pollution.
- Removal, refitment or associated labour charges.
- Products not originally sold in Australia through authorised channels.
Warranty Claim Process
- Retain proof of original purchase.
- Return the product through the original place of purchase where applicable.
- If claiming directly, obtain a case number before returning goods.
- Products must be securely packed and clearly identified.
- Warranty assessment determines repair, replacement or refund.
Australian Consumer Law
Lockwood warranties operate in addition to rights available under the Australian Consumer Law. Goods come with guarantees that cannot be excluded. Customers may be entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage.
Where a product fails to meet acceptable quality standards and the failure does not amount to a major failure, the customer is entitled to repair or replacement.
