Kaba Door Closer EN2-5 including Standard Arm and PA Bracket - Silver
The dormakaba 9025 Series is a surface mounted door closer designed for architectural and commercial applications where a compact, multi function closer is required. It is non handed and suitable for doors up to 1250 mm wide.
Fire rated: Successfully tested up to 4 hours (depending on door set type) on fire door assemblies in accordance with AS 1905.1-2005 Part 1.
Key Features
- Adjustable closing force power size EN2-5 (one closer covers multiple power sizes).
- Adjustable closing speed and latching speed.
- Backcheck (valve adjustable) beyond approximately 60°.
- Delayed action between approximately 180° and 65°.
- Compact extruded aluminium body with minimal projection for tight installations.
- Supplied with standard arm and parallel arm bracket (PA).
- Fixing screws supplied to suit timber or metal fixing (as supplied).
- Supplied boxed.
Specifications
- Item Code: 9025SIL
- Brand: Dormakaba
- Product Type: Surface mounted door closer
- Spring Strength: EN2-5 (adjustable)
- Non handed: Yes
- Max door width: 1250 mm
- Adjustable closing speed: Yes
- Adjustable latching speed: Yes
- Backcheck: Yes
- Delayed action: Yes
- Parallel arm bracket included: Yes
- Has hold open: No
- Fire rated: Yes
- Finish: Silver
What's In The Box
- 1 x Dormakaba 9025 series door closer body
- 1 x Standard arm set
- 1 x Parallel arm bracket (PA bracket)
- Fixing screws (as supplied)
Suitable Uses
- Commercial and architectural swing doors requiring adjustable closing power (EN2-5).
- Fire door applications where a tested door closer is required (confirm door set requirements).
- Doors needing backcheck and delayed action for controlled operation in high traffic areas.
Dimensions
| Dimension | Size |
| Length | 236 mm |
| Height | 60 mm |
| Depth | 38.5 mm |
Frequently Asked Questions
- Does this door closer include a parallel arm bracket?
Yes. This model includes a PA bracket (parallel arm bracket) as standard. - Is this closer handed?
No. The 9025 series is non handed, suitable for left or right handed swing doors. - Can I adjust the closing and latching speed?
Yes. Closing speed and latching speed are adjustable, and it also includes backcheck and delayed action.
Additional Information
- When setting EN power size, confirm the door size, weight and site conditions to avoid slamming or poor latch engagement.
- Backcheck helps protect doors and frames from impact, especially where doors can be opened forcefully.
- Delayed action can assist with accessibility and trolleys where a longer open time is beneficial.
.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our
Returns & Warranty page
� this is kept up to date and is the authoritative reference for current claim steps.
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
