Dormakaba Sliding Primary Mortice Lock MS2603 - Satin Stainless Steel
Key Features
- Primary mortice sliding door hook bolt lock.
- 20 mm stainless steel hook bolt for secure engagement.
- 304 grade stainless steel case, cover, and faceplate.
- Operated by key externally and turnsnib or key internally.
- Compatible with most restricted keying systems.
- Commercial grade construction for sliding door applications.
- Non-handed design for easier installation.
Fire Rated
- Fire-rated configuration available when installed in compliant door assemblies.
Specifications
- Item Code: DKMS2603SSS
- Lock Type: Sliding door mortice hook bolt
- Backset: 60 mm
- Door Thickness: 32 mm to 50 mm
- Hook Bolt: 20 mm stainless steel
- Cylinder Type: 570 oval cylinder (not included)
- Handing: Non-handed
- Material: 304 grade stainless steel
- Finish: Satin Stainless Steel
- Face Plate: 175 x 25 x 4 mm
- Case Size: 120 x 84 x 19 mm
- Security Rating: SL8 (AS4145.2-2008)
- Durability Rating: D8 (AS4145.2-2008)
What's In The Box
- Dormakaba MS2603 sliding mortice lock body
- Faceplate
- Fixing screws
Suitable Uses
- Commercial sliding doors requiring a high security hook bolt.
- Retail, office, and industrial sliding door applications.
- Domestic sliding doors where a keyed hook bolt is required.
Dimensions
| Measurement | Value |
|---|---|
| Backset | 60 mm |
| Door Thickness | 32 mm to 50 mm |
| Face Plate | 175 x 25 x 4 mm |
| Case Size | 120 x 84 x 19 mm |
Frequently Asked Questions
- Does this lock include a cylinder?
No. The lock is supplied less cylinder and requires a compatible 570 oval cylinder. - Is this suitable for commercial sliding doors?
Yes. It is a commercial grade sliding door mortice lock with high security hook bolt. - What is the advantage of a hook bolt?
The hook bolt engages into the strike, making it harder to force the sliding door open.
Additional Information
- Primary locks are typically used as the main locking point on sliding door systems.
- Often paired with secondary locks or flush bolts for large or multi-panel sliding doors.
- Compatible with restricted keying systems for higher security installations.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our
Returns & Warranty page
� this is kept up to date and is the authoritative reference for current claim steps.
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
