Dormakaba Panic Exit Device Horizontal Mortice Lock Type 1085mm (Cuts Back to 645mm) - Satin Stainless Steel
Key Features
- Horizontal panic exit device designed for mortice lock applications.
- Supplied complete with compatible MS2ED mortice lock.
- Standard bar length 1085 mm, field cuttable down to 645 mm.
- Field selectable handing for left or right hand doors.
- Hex key dogging supplied for temporary hold open function.
- Mounting plates and through-fixing screws included for timber doors.
- Suits door thickness from 35 mm to 50 mm as standard.
- Satin Stainless Steel finish for commercial applications.
Specifications
- Item Code: ED22MSSS
- Brand: Dormakaba
- Device Type: Horizontal panic exit device with mortice lock
- Standard Length: 1085 mm
- Minimum Cut Length: 645 mm
- Door Thickness: 35 mm to 50 mm
- Handing: Field selectable
- Dogging: Hex key (Allen key) type supplied
- Finish: Satin Stainless Steel
- Fire Rated: No
- Locking Mode: Locking horizontal device with mortice lock
What's In The Box
- Horizontal panic exit device (cuttable bar)
- MS2ED mortice lock
- Mounting plates
- Through-fixing screws
- Hex key dogging mechanism
Suitable Uses
- Commercial exit doors requiring mortice lock security.
- Offices, schools, and public buildings needing fast emergency egress.
- Timber door applications within standard thickness ranges.
Dimensions
Frequently Asked Questions
- Is this product suitable for fire doors?
No. This specific configuration is not fire rated. A fire-rated exit device must be selected when required by building codes. - Does this include the mortice lock?
Yes. This model is supplied complete with the compatible MS2ED mortice lock. - Can the bar be cut to suit smaller doors?
Yes. The standard 1085 mm bar can be cut on site down to a minimum length of 645 mm.
Additional Information
- Commonly specified in Australian commercial buildings where a mortice lock is required for added security alongside emergency egress.
- The dogging function is typically used during business hours to allow free access without constant bar operation.
- Installers should confirm door thickness and backset requirements before cutting the bar to length.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our
Returns & Warranty page
� this is kept up to date and is the authoritative reference for current claim steps.
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
Further Information
