Dormakaba Furniture Square End Plate Concealed Fix with Emergency Turn and Noosa Lever – Satin Stainless Steel
Key Features
- External square end plate with integrated Noosa lever and emergency coin turn.
- AS1428.1 compliant lever profile for accessible installations.
- Slotted coin turn allows emergency unlocking using a coin or flat blade.
- Manufactured from solid 316 grade stainless steel.
- Concealed fixing for a clean external appearance.
- Successfully tested up to 4 hours on fire door assemblies (doorset dependent).
Fire Rated
- Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with AS 1905.1:2005, Part 1: Fire Resistant Doorsets.
Specifications
- Item Code: DO660430SSS
- Brand: Dormakaba
- Product Type: External plate furniture with lever and emergency slot turn
- Plate Style: Square end plate
- Lever: Noosa lever profile (30 series)
- Emergency Turn: Slotted coin turn
- Fixing: Concealed fixing
- Material: Solid stainless steel
- Stainless Steel Grade: 316
- Designed to suit: Dormakaba DKMS2602SSS series locks
- Door Thickness: 32–50 mm
- Fixing Centres: 148 mm
- Handing: Non-handed
- Compliance: AS1428.1 compliant lever design
- Fire Rated: Yes - tested up to 4 hours (doorset dependent)
- Finish: Satin Stainless Steel
- Plate Size: 165 mm × 45 mm × 10 mm
What's In The Box
- External square end plate with Noosa lever and emergency coin turn
- Fixing screws for external plate installation
Suitable Uses
- External doors requiring a lever with emergency access capability.
- Fire door assemblies where tested hardware is required (confirm doorset approval requirements).
- Commercial and institutional fit-outs requiring AS1428.1 compliant lever access.
- Coastal or corrosive environments where 316 stainless steel is preferred.
Dimensions
Frequently Asked Questions
- What is the emergency slot turn used for?
It allows emergency unlocking using a coin or flat blade tool when the lock function requires an external override. - Is this product suitable for fire doors?
It has been successfully tested up to 4 hours on fire door assemblies to AS 1905.1:2005 (doorset dependent). Always confirm your specific doorset approval and hardware schedule requirements. - What lock does this suit?
It is designed for use with dormakaba DKMS2602SSS series locks. Confirm door preparation, plate footprint, and fixing centres match before ordering.
Additional Information
- Emergency turns are commonly specified for amenities and managed facilities where staff may need a simple external override method.
- On fire doors, installers typically confirm the complete hardware set (lock, spindle, furniture, and door leaf preparation) matches the approved doorset configuration.
- Concealed fixing can look cleaner on external doors, but it can take longer to service than visible fix furniture in high traffic environments.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our
Returns & Warranty page
� this is kept up to date and is the authoritative reference for current claim steps.
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
