Dormakaba Furniture Narrow Round End Plate Concealed Fix with Cylinder Hole & Noosa Lever - Satin Stainless Steel

Dormakaba

$216.48
(No reviews yet) Write a Review
SKU:
STK DO650030SSS
UPC:
9322844097970
Availability:
Usually same day dispatch (if ordered before 11am)
Adding to cart… The item has been added
Dormakaba logo

Dormakaba Furniture Narrow Round End Plate with Cylinder Hole and Noosa Lever – Satin Stainless Steel

Key features icon Key Features

  • Narrow exterior round end plate with integrated Noosa lever.
  • Designed for use with compatible dormakaba mortice locks.
  • AS1428.1 compliant lever profile for accessible installations.
  • Manufactured from solid 316 grade stainless steel.
  • Concealed fixing for a clean external appearance.
  • Plates designed for back-to-back installation.

Specifications icon Specifications

  • Item Code: DO650030SSS
  • Brand: Dormakaba
  • Product Type: Exterior narrow plate furniture with lever
  • Plate Style: Narrow round end plate
  • Lever: Noosa lever profile
  • Cylinder Hole: Oval cylinder cut-out
  • Material: Solid stainless steel
  • Stainless Steel Grade: 316
  • Door Thickness: 32–50 mm
  • Fixing Centres: 160 mm
  • Handing: Reversible
  • Compliance: AS1428.1 accessible lever design
  • Finish: Satin Stainless Steel

Contents icon What's In The Box

  • Exterior narrow round end plate with Noosa lever
  • Fixing screws for external plate installation

Suitable uses icon Suitable Uses

  • Commercial entry doors using dormakaba mortice locks.
  • External doors requiring corrosion resistant stainless steel hardware.
  • Accessible doorways requiring AS1428.1 compliant lever design.
  • Schools, healthcare, hospitality, and public buildings.

Dimensions icon Dimensions

Dimension Size
Plate Length 185 mm
Plate Width 26 mm
Plate Thickness 12.7 mm
Fixing Centres 160 mm

FAQ icon Frequently Asked Questions

  • Is this plate suitable for fire doors?
    Suitability depends on the complete door assembly and the mortice lock used. Fire rating must be confirmed at the door and lock level.
  • Does this include both internal and external plates?
    This item is the external plate only. The internal plate and lock components must be ordered separately.
  • What is a common installation mistake to avoid?
    Incorrect fixing centre alignment with the mortice lock can prevent proper back-to-back installation. Always confirm lock compatibility before fitting.

Additional information icon Additional Information

  • Commonly specified on commercial entry doors where narrow stile or aluminium framing limits plate width.
  • 316 grade stainless steel construction is typically chosen for coastal or high corrosion environments.
  • AS1428.1 compliant lever profile makes this suitable for accessible doorways in public buildings.
  • Designed to be paired with compatible dormakaba mortice locks and matching internal plates.

dormakaba Warranty

dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.

Warranty Summary

Warranty Provider dormakaba Australia Pty Ltd (ABN 14 067 969 466)
Coverage Region Australia
Warranty Starts Date of purchase
Registration Required No
Mechanical Products (general) 10 years
Digital Door Locks � electronic components 1 year
Electric Locks � electronic components 1 year
Electric Strikes 5 years
Hinges 2 years
Safe Locks 2 years
Entrance Control / Access Systems 2 years
Push Button Locks 2 years from date of manufacture
Interior Glass Systems � mechanical 2 years
Automatic Operators 2 years (labour: 1 year from installation by dormakaba technician or authorised representative)
EL301 & AL401 Automatic Operators � motor & gearbox 10 years when serviced in accordance with AS5007
Powder Coated Finishes 1 year (leading edges: no warranty)
Electroplated Finishes 1 year
PVD (Physical Vapour Deposition) Finishes 10 years
Plated Finishes (black chrome, satin chrome, polished chrome, oiled nickel, bronze, polished bronze) No warranty � deterioration is anticipated under some climatic conditions
Batteries (Electric Mortice Locks & Digital Door Locks) No warranty

How to Make a Claim

For full returns and warranty claim procedures, visit our Returns & Warranty page � this is kept up to date and is the authoritative reference for current claim steps.
  1. Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
  2. Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
  3. Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
  4. Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.

Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.

Exclusions

This warranty does not cover:

  • Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
  • Fair wear and tear
  • Damage arising from installation not carried out by dormakaba or its authorised agents
  • Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
  • Damage caused by circumstances beyond dormakaba's control
  • Defects within acceptable industry variances
  • Products used other than for their intended purpose
  • Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
  • Products that have been modified, built on, or repaired by a third party
  • Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
  • Routine maintenance items (the purchaser's responsibility)
  • Products installed, maintained, or operated other than in accordance with dormakaba's instructions
  • Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim

Important Notes

Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
