Dormakaba Furniture 6604/39 Manly – External Plate with Emergency Coin Turn – Satin Stainless Steel
The Dormakaba 6604/39 Manly is a 6600 series external square end plate furniture set that pairs a Manly 39 series lever with a slotted emergency coin turn. It is manufactured from 316 grade corrosion resistant stainless steel and is designed for use with dormakaba DKMS2602SSS series locks.
The supplied information states the lever is disability access compliant to AS1428.1 (2009) and the furniture has been successfully tested on fire door assemblies up to 4 hours (depending on the doorset) to AS1905.1 (2005) Part 1.
Key Features
- External rectangular square end plate with Manly 39 series lever and slotted emergency coin turn.
- 316 grade corrosion resistant stainless steel construction.
- AS1428.1 (2009) compliant lever (as specified in supplied information).
- Concealed fixing for a cleaner external presentation.
- Fire tested on doorset assemblies up to 4 hours (depending on doorset type) to AS1905.1 (2005) Part 1 (as specified in supplied information).
Fire Rated
- Successfully tested up to 4 hours on fire door assemblies (depending on type of doorset) in accordance with AS1905.1:2005 Part 1, as stated in the supplied information.
Specifications
- Item Code: DO660439SSS
- Product Name: 6604/39 Manly external plate furniture
- Application: External
- Plate Type: Square end plate (rectangular)
- Plate Has A Lever: Yes
- Plate Has An Emergency Slot Turn: Yes
- AS1428.1 Compliant Lever: Yes (as specified in supplied information)
- Material: 316 grade stainless steel
- Finish: Satin stainless steel
- Fixing: Concealed
- Door Thickness: 32 mm to 50 mm
- Plate Size: 165 mm × 45 mm × 10 mm
- Fixing Centres: 148 mm
- Compatible Locks: dormakaba DKMS2602SSS series locks
What's In The Box
- 1 × External 6600 series plate with Manly 39 lever and slotted emergency coin turn
- Fixing screws
Suitable Uses
- External doors where an outside lever is required with an emergency coin turn for external release (used with a compatible lock function).
- Commercial and institutional sites specifying 316 grade stainless steel hardware, including coastal and high humidity environments.
- Accessibility focused sites requiring an AS1428.1 compliant lever (where specified and approved for the doorset).
- Fire door assemblies where tested plate furniture is required, subject to the specific doorset approval and hardware schedule.
Dimensions
| Dimension | Size |
|---|---|
| Plate Height | 165 mm |
| Plate Width | 45 mm |
| Plate Thickness | 10 mm |
Frequently Asked Questions
- Is this plate set internal or external?
This model is specified as an external plate furniture set. - What does the emergency coin turn do?
It provides a slotted external turn that can be operated with a coin or flat tool to release the lock function, depending on the lock configuration. - Does the 4 hour fire testing guarantee it suits every fire doorset?
The supplied information states testing up to 4 hours depending on the doorset. Fire door suitability is normally confirmed against the complete doorset approval and the specific hardware schedule.
Additional Information
- Emergency coin turns are commonly specified on external plates where free egress is managed internally, but authorised external access may be required without issuing a key.
- Because this is an external plate, concealed fixing helps reduce tampering points, but installers still typically confirm door preparation suits the fixing method before drilling.
- On fire and smoke door assemblies, plate furniture selection is usually checked against doorset evidence because door construction, reinforcement, and preparation can affect allowable hardware sets.
