Brava Metro EL Series Entrance Lockset – Knob / Lever – 70 mm Backset
The Brava Metro EL Series Entrance Lockset – Knob / Lever – 70 mm Backset is a commercial grade cylindrical entrance lockset combining an external spherical knob with an internal lever. This configuration is commonly used where keyed external access is required while maintaining lever operation on the internal side.
Estimated Warehouse Dispatch: Usually same day dispatch (if ordered before 11am)
Key Features
- Entrance function with keyed external knob.
- Internal lever free at all times for egress.
- Internal push button locks the external knob.
- External spherical knob with internal straight lever.
- Cylindrical fixing with anti-rotation fixing points.
- Silca LW5 profile 6 pin cylinder.
- Incorporates the PD 8221 barrel.
- Compatible with most restricted keying systems.
- Supplied boxed and colour coded with mounting hardware.
- Two keys supplied.
Fire Rated
- Successfully tested up to 4 hours on fire door assemblies in accordance with AS 1905.1-2005, subject to doorset configuration.
Disability Act Compliance
- Internal lever only complies with AS1428.1 accessibility requirements.
- External spherical knob does not comply with AS1428.1.
- This lockset may not be suitable for accessible paths of travel.
- Compliance must be confirmed with the project certifier.
Specifications
- Function: Entrance
- Lock Configuration: Knob / Lever
- Lock Type: Cylindrical
- Lock Grade: Commercial
- Backset: 70 mm
- Door Thickness: 35 mm to 45 mm
- Maximum Projection: 54 mm (lever), 68 mm (knob)
- Rose Diameter: 75 mm
- Latch Face Plate: 57 mm × 25 mm
- Strike: 70 mm × 28 mm × 2 mm
- Cylinder: LW5 profile
- Door Handing: Non-handed
Suitable Uses
- Commercial entry doors requiring keyed external access.
- Rooms where internal lever operation is preferred.
- Fire rated door assemblies where compliant hardware is required.
Available Colour Variants
-
Polished Brass
EL3100PB70 -
Satin Chrome
EL3000SC70
Download PDF Resources
|
Brava Commercial Hardware Catalogue 2024 |
Frequently Asked Questions
Is this lockset fully DDA compliant?
No. Only the internal lever complies with AS1428.1. The external knob does not.
Is this suitable for fire doors?
Yes, when installed as part of a compliant fire rated doorset tested to AS 1905.1.
Can this be keyed alike with other Brava Metro locks?
Yes. LW5 cylinders allow keying alike where compatible systems are used.
Additional Information
- This knob/lever configuration is commonly used where lever operation is required internally.
- DDA compliance must be assessed in the context of the full door hardware schedule.
- Fire rating applies to the doorset configuration, not the finish.
