Lockwood Left Hand Offset 3 Degree Extended Spindle +15mm - ST80-60-15LH
The Lockwood ST80-60-15LH Extended Spindle is a left hand offset 3 degree extended pivot insert designed for use with Lockwood ST8011 Series floor spring closers and pivot kits. It provides +15mm additional clearance where extra space is required between the door and finished floor level.
This extended spindle is commonly used where thresholds, carpeted floors, raised floor finishes or retrofit conditions require additional clearance. The left hand configuration and 3 degree offset must match the door setup for correct pivot alignment and smooth operation.
The ST80-60-15LH forms part of the Lockwood ST8011 extended spindle range and is suited to commercial door hardware maintenance, replacement and installation work.
Typically ships in 2-3 business days.
Key Features
- Left hand offset 3 degree extended spindle insert
- Provides +15mm additional clearance
- Suits Lockwood ST8011 Series floor spring closers and pivot kits
- Interchangeable extended pivot insert for floor spring applications
- Helps accommodate thresholds, carpeted floors and raised floor finishes
- Supports correct door to floor clearance and pivot alignment
Suitable Uses
- Lockwood ST8011 Series floor spring closer installations
- Commercial aluminium door systems
- Threshold clearance applications
- Carpeted or raised floor environments
- Retrofit door hardware work where finished floor height has changed
Full Specifications
Dimensions
Item Code Family
Frequently Asked Questions
Is this spindle suitable for all Lockwood floor closers?
No. The supplied product data states it suits Lockwood ST8011 Series floor spring closers and pivot kits. Compatibility should be checked against the installed floor spring system.
When would a +15mm extended spindle be used?
It is used where additional clearance is needed between the door and finished floor level, such as threshold, carpeted floor or raised floor finish applications.
What is a common installation mistake to avoid?
Do not select the spindle by extension length only. Handing, offset direction, floor clearance and pivot alignment must all match the door installation.
Additional Information
- The necessary spindle extension is calculated from the required floor clearance and the collar height of the extended spindle insert.
- The standard spindle insert collar height reference is 3mm, which should be considered when calculating spindle extension length.
- Extended spindle inserts are commonly required when flooring has been added or changed after the original door closer installation.
- This type of part is commonly specified in Australian commercial door hardware maintenance and retrofit work.
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship for:
- Mechanical components: 25 years
- Electrical and electronic components: 2 years (excluding batteries)
