Dormakaba TS93B Pull Side Door Closer – Cam Action Slide Arm – Adjustable EN1-5
Key Features
- Cam action door closer with heart-shaped cam mechanism.
- Adjustable closing force EN1 to EN5.
- Slide channel arm assembly for smooth operation.
- Adjustable closing speed and latching speed.
- Integrated backcheck and delayed action adjustment.
- Non-handed design for flexible installation.
- Suitable for single and double doors up to 1250 millimetres wide.
- Fire rated when installed on compliant fire door assemblies.
Fire Rated
- Suitable for fire and smoke check doors when installed to compliant door set specifications.
Specifications
- Item Code: DOTS93BN
- Model: TS93B
- Installation: Pull side door leaf fixing or push side transom fixing
- Spring Strength: EN1-5 adjustable
- Maximum Door Width: 1250 millimetres
- Arm Type: Slide channel arm
- Closing Speed: Adjustable
- Latching Speed: Adjustable
- Backcheck: Adjustable
- Delayed Action: Adjustable
- Hold Open: No
- Handing: Non-handed
- Fire Rated: Yes
- Finish: Silver
- Body Dimensions: 275 x 53 x 60 millimetres
- Weight: 3.5 kilograms
- Standard: Tested to EN1154
What's In The Box
- Dormakaba TS93B door closer body
- Slide channel arm assembly
- Fixing screws and mounting hardware
Suitable Uses
- Commercial and institutional doors up to 1250 millimetres wide.
- Fire and smoke check door assemblies.
- Single or double door installations.
Dimensions
Frequently Asked Questions
- Is this closer suitable for fire doors?
Yes. It is suitable for fire and smoke check doors when installed in accordance with the door set requirements. - Can the closing force be adjusted on site?
Yes. The spring strength can be adjusted between EN1 and EN5 using the adjustment screw. - Does this model include a hold-open function?
No. This version does not include a hold-open arm. Hold-open is available as an optional configuration in the range.
Additional Information
- Cam action design provides lower opening resistance compared with traditional rack and pinion closers, improving accessibility.
- Commonly specified on commercial fire doors in offices, hospitals, and education facilities.
- Delayed action and backcheck adjustments help control door movement in high traffic environments.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our
Returns & Warranty page
� this is kept up to date and is the authoritative reference for current claim steps.
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
