Dormakaba Primary Mortice Deadbolt 60 mm Backset – MS2600 Series
Dormakaba MS2600 series primary mortice deadbolt and mortice lock options designed for commercial applications where a robust stainless steel locking platform is required. This range includes both a dedicated deadbolt model and a function-adaptable primary mortice lock, sharing a common 60 mm backset and construction platform.
Key Features
- Commercial grade mortice locking platform.
- 60 mm backset as standard across the MS2600 series.
- 304 grade stainless steel case, cover and faceplate.
- Compatible with most restricted keying systems.
- Designed for use with oval profile cylinders.
Fire Rated
- MS2602 variant fire rated up to 4 hours when installed as part of a certified doorset.
Specifications
What's In The Box
- Mortice lock or deadbolt body (variant dependent).
- Faceplate and strike.
- Turn snib adaptor supplied with MS2602 only.
Suitable Uses
- Commercial timber doors.
- High security applications requiring mortice deadbolts.
- Doors using restricted keying systems.
Available Variants
Item Code Family
Download PDF Resources
Frequently Asked Questions
Is the MS2601 the same as the MS2602?
No. The MS2601 is a dedicated deadbolt, while the MS2602 is a function-adaptable mortice lock with latch and anti-lockout.
Are cylinders supplied?
No. Cylinders are supplied separately to suit the required keying system.
Can these locks be used on aluminium doors?
No. Aluminium doors require SB2200 series narrow stile mortice locks.
Additional Information
- MS2602 is supplied with a turn snib adaptor as standard.
- MS2601 does not include a latch or anti-lockout function.
- Fire rating applies only when installed as part of a certified fire doorset.
dormakaba Warranty
dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
- Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
- Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
- Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
- Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.
Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.
Exclusions
This warranty does not cover:
- Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
- Fair wear and tear
- Damage arising from installation not carried out by dormakaba or its authorised agents
- Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
- Damage caused by circumstances beyond dormakaba's control
- Defects within acceptable industry variances
- Products used other than for their intended purpose
- Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
- Products that have been modified, built on, or repaired by a third party
- Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
- Routine maintenance items (the purchaser's responsibility)
- Products installed, maintained, or operated other than in accordance with dormakaba's instructions
- Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim
Important Notes
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
