Dormakaba Door Closer TS72 EN2-4 with Parallel Arm Bracket - Silver

Dormakaba

Was: $476.84
Now: $394.88
(No reviews yet) Write a Review
SKU:
STK DOTS7200SIL
UPC:
4021226271896
Availability:
Usually same day dispatch (if ordered before 11am)
Adding to cart… The item has been added
Dormakaba logo

Dormakaba Door Closer TS72 EN2-4 with Parallel Arm Bracket - Silver

Key features icon Key Features

  • Non handed overhead surface mounted door closer.
  • Adjustable spring strength EN2 to EN4.
  • Two independent valves for closing and latching speed adjustment.
  • Integrated backcheck to reduce door impact.
  • Parallel arm bracket included.
  • Suitable for doors up to 1100 mm wide.
  • Fire rated model.
  • Silver finish.

Fire rating icon Fire Rated

  • Approved to AS1905.1 fire resistant doorsets when installed in accordance with manufacturer instructions.

Specifications icon Specifications

  • Item Code: DOTS7200SIL
  • Closer Series: TS72
  • Spring Strength: EN2-4
  • Mounting Type: Surface mounted
  • Handing: Non handed
  • Closing Speed: Adjustable
  • Latching Speed: Adjustable
  • Backcheck: Yes
  • Delayed Action: No
  • Hold Open: No
  • Parallel Arm Bracket: Included
  • Maximum Door Width: 1100 mm
  • Finish: Silver

Contents icon What's In The Box

  • 1 x TS72 door closer body
  • 1 x Standard arm assembly
  • 1 x Parallel arm bracket
  • Fixing screws and installation template

Suitable uses icon Suitable Uses

  • Internal commercial and residential doors.
  • Office, retail and light commercial applications.
  • Fire rated doors when installed to compliant doorsets.

Dimensions

TS72 door closer dimensions
Dimension Size
Body Length 232 mm
Body Width 45 mm
Body Height 68 mm
Weight 1.2 kg

PDF icon Download PDF Resources

PDF icon Dormakaba TS72 Door Closer Brochure

FAQ icon Frequently Asked Questions

  • Is the TS72 door closer handed?
    No. The TS72 is non handed and can be installed on left or right hand doors.
  • Does this closer include hold open?
    No. This model does not include a hold open function.
  • Can this be installed on fire doors?
    Yes, it is approved for fire door use when installed to compliant doorsets.

Book icon Additional Information

  • The TS72 is commonly used as a general purpose closer for light to medium duty commercial doors.
  • Closing force is adjusted by installation position according to the template.
  • Always follow the manufacturer installation instructions for correct fire door compliance.

Technical Drawing

TS72 door closer technical drawing

dormakaba Warranty

dormakaba Australia Pty Ltd (ABN 14 067 969 466) provides the following warranty on all dormakaba branded products sold in Australia. This warranty is in addition to, and does not limit, your rights under the Australian Consumer Law.

Warranty Summary

Warranty Provider dormakaba Australia Pty Ltd (ABN 14 067 969 466)
Coverage Region Australia
Warranty Starts Date of purchase
Registration Required No
Mechanical Products (general) 10 years
Digital Door Locks � electronic components 1 year
Electric Locks � electronic components 1 year
Electric Strikes 5 years
Hinges 2 years
Safe Locks 2 years
Entrance Control / Access Systems 2 years
Push Button Locks 2 years from date of manufacture
Interior Glass Systems � mechanical 2 years
Automatic Operators 2 years (labour: 1 year from installation by dormakaba technician or authorised representative)
EL301 & AL401 Automatic Operators � motor & gearbox 10 years when serviced in accordance with AS5007
Powder Coated Finishes 1 year (leading edges: no warranty)
Electroplated Finishes 1 year
PVD (Physical Vapour Deposition) Finishes 10 years
Plated Finishes (black chrome, satin chrome, polished chrome, oiled nickel, bronze, polished bronze) No warranty � deterioration is anticipated under some climatic conditions
Batteries (Electric Mortice Locks & Digital Door Locks) No warranty

How to Make a Claim

For full returns and warranty claim procedures, visit our Returns & Warranty page � this is kept up to date and is the authoritative reference for current claim steps.
  1. Report the defect promptly. Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) as your point of sale in the first instance. Claims must be lodged no later than 1 month from the date the defect becomes obvious.
  2. Prepare your documentation. You will need proof of purchase (invoice or receipt), the date of delivery or installation, your name and address, and any maintenance records relevant to the product.
  3. Make the product available for inspection. dormakaba requires adequate access to the goods, fittings, and fixtures to assess any warranty claim and carry out repairs. If no fault is found, dormakaba's standard costs for inspection, service, and testing apply.
  4. Warranty work is conducted during normal business hours � 8:00am to 5:00pm, Monday to Friday.

Note: The expense of making a warranty claim (including transport and access costs) is borne by the purchaser.

Exclusions

This warranty does not cover:

  • Damage or defects caused by misuse, abuse, neglect, or failure to follow dormakaba's selection, installation, and maintenance instructions
  • Fair wear and tear
  • Damage arising from installation not carried out by dormakaba or its authorised agents
  • Damage caused to the structures the product is installed in, where installation was not by dormakaba or its authorised agents
  • Damage caused by circumstances beyond dormakaba's control
  • Defects within acceptable industry variances
  • Products used other than for their intended purpose
  • Damage from exposure to abnormal conditions, including but not limited to extreme temperature, water, fire, humidity, pressure, or stress
  • Products that have been modified, built on, or repaired by a third party
  • Products not maintained in accordance with dormakaba's care, cleaning, and maintenance instructions (as amended from time to time on the dormakaba website)
  • Routine maintenance items (the purchaser's responsibility)
  • Products installed, maintained, or operated other than in accordance with dormakaba's instructions
  • Overhaul, replacement, or repair work carried out prior to dormakaba's approval of a warranty claim

Important Notes

Australian Consumer Law
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. Nothing in this warranty limits or excludes these statutory rights.
Replacement & Repair
dormakaba reserves the right to replace defective parts with components of similar quality, grade, and composition where an identical part is unavailable. Refurbished parts or goods of the same type may be used. For discontinued or unavailable products, dormakaba may substitute an equivalent current product. All products replaced under warranty become the property of dormakaba.
