Dormakaba Door Closer TS68 BC EN2-4 with Parallel Arm Bracket - Silver
Key Features
- Non handed overhead surface mounted door closer.
- Adjustable power size EN2 to EN4 via arm templating.
- Two independent valves for closing and latching speed adjustment.
- Backcheck function to reduce door impact.
- Parallel arm bracket included.
- Suitable for standard doors up to 1100 mm wide.
- Fire rated model when installed to compliant doorsets.
- Silver finish.
Fire Rated
- Approved to AS1905.1 fire resistant doorsets when installed in accordance with manufacturer instructions.
- Backcheck model suitable for fire door applications.
Specifications
- Item Code: DOTS6800SIL
- Closer Series: TS68
- Spring Strength: EN2-4
- Mounting Type: Surface mounted
- Handing: Non handed
- Closing Speed: Adjustable
- Latching Speed: Adjustable
- Backcheck: Yes
- Delayed Action: No
- Hold Open: No
- Parallel Arm Bracket: Included
- Maximum Door Width: 1100 mm
- Finish: Silver
What's In The Box
- 1 x TS68 door closer body
- 1 x Standard arm assembly
- 1 x Parallel arm bracket
- Fixing screws and installation template
Suitable Uses
- Internal commercial and residential doors.
- Office, retail and light commercial applications.
- Fire rated doors when installed to compliant doorsets.
Dimensions
Download PDF Resources
|
Dormakaba TS68 Door Closer Brochure |
Frequently Asked Questions
- Is this door closer handed?
No. The TS68 is non handed and can be installed on left or right hand doors. - Does this closer include a hold open function?
No. This model does not include a hold open feature. - Can this be used on fire doors?
Yes, the backcheck model is approved for fire door use when installed to compliant doorsets.
Additional Information
- The TS68 is commonly used as a cost effective solution for light to medium duty commercial doors.
- Power size is set by installation position rather than internal spring adjustment.
- Always refer to the installation template to select the correct EN power size.
Technical Drawing
