ABUS Oval Cylinder – Polished Brass – Keyed to Differ – X & Z Cams
The ABUS AB570UCYLPBKD is a precision 6 pin British oval cylinder supplied keyed to differ and finished in polished brass. It is designed for standard oval mortice locks commonly specified in Australian commercial and institutional door hardware.
Key Features
- Precision 6 pin British oval cylinder.
- Supplied keyed to differ.
- X cam fitted as standard.
- Z cam supplied separately.
- Suitable for most standard oval mortice locks.
- Traditional polished brass finish.
Specifications
- Brand: ABUS
- Item Code: AB570UCYLPBKD
- Cylinder Profile: British oval
- Pin Configuration: 6 pin
- Keying: Keyed to differ
- Key Profile: LW5
- Keys Supplied: 2
- Finish: Polished Brass
- Cam Configuration: X cam fitted, Z cam included
What’s In The Box
- 1 × ABUS oval cylinder (X cam fitted)
- 1 × Z cam
- 2 × keys
ABUS 570 Oval Cylinders – Item Code Family
| Item Code | Type | Finish | Keying | Notes |
|---|---|---|---|---|
| AB570UCYLPBKD | Standard oval | Polished Brass | Keyed to differ | This product |
| AB570UCYLSCKA1 | Standard oval | Satin Chrome | Keyed alike | KA group |
| AB570UCYLNPKD | Standard oval | Nickel Plate | Keyed to differ | X & Z cams supplied |
| AB570UEXCYL50SCKD | Extended oval | Satin Chrome | Keyed to differ | 50 mm extension |
| AB570UEXCYL62SCKD | Extended oval | Satin Chrome | Keyed to differ | 62 mm extension |
Frequently Asked Questions
Does this cylinder suit all oval mortice locks?
It suits most British oval mortice locks. Cam type and door thickness should always be confirmed.
Are both cams supplied?
Yes. X cam is fitted and Z cam is supplied separately.
Can this be keyed alike?
This SKU is keyed to differ. Keyed alike versions use different item codes.
Additional Information
- British oval cylinders are standard in Australian commercial door hardware.
- Supplying both cam types improves site compatibility.
- Finish selection does not affect cylinder performance.
ABUS Warranty
ABUS products sold by Terry’s Tradies Pty Ltd and its associated websites and subsidiaries are backed by a manufacturer’s warranty covering defects in materials and workmanship, and your rights under the Australian Consumer Law (ACL). Warranty periods vary by product line — refer to your product packaging or contact us at the time of purchase for the period that applies to your specific model.
Warranty Summary
How to Make a Warranty Claim
- Contact Terry’s Tradies Pty Ltd at your original place of purchase first — all warranty claims must be directed to the retailer where the product was purchased.
Phone: 07 5601 1867
Visit: U9/2 Prosper Crescent, Burleigh Heads QLD 4220 - Have your proof of purchase ready (receipt or order confirmation).
- If the fault is not immediately visible in person, provide clear photos showing the defect so the item can be assessed before a Return Merchandise Authorisation (RMA) is approved.
- Do not return the item before receiving RMA approval — items returned without approval may be sent back to you at your cost.
- Once approved, you will receive return instructions. If the item is confirmed faulty, a prepaid return freight label will be provided to cover return shipping costs.
What the Warranty Does Not Cover
- Normal wear and tear
- Damage caused by misuse, abuse, or improper installation
- Damage caused by neglect or failure to follow product instructions
- Products not purchased from an authorised retailer
Warranty claims must be lodged with the retailer where the product was originally purchased. ABUS products purchased from another retailer or website cannot be returned to Terry’s Tradies Pty Ltd and its associated websites and subsidiaries for warranty assessment.
