Lockwood 3570 Series Cylinder Retainer Pin (Box of 10) SP3570-5039
The Lockwood 3570 Series Cylinder Retainer Pin is used to secure oval cylinders within Lockwood mortice lock bodies. Supplied in a box of 10, these pins are suited for installation, servicing, and replacement work.
The retainer pin passes through the lock body beneath the cover plate, engaging the cylinder and holding it firmly in position. The correct pin length is determined by the lock backset, making selection critical for proper operation.
This version is designed to suit 60mm backset Lockwood mortice locks and is commonly used by locksmiths during maintenance or retrofit work.
- Designed for Lockwood 3570 series mortice locks
- Supplied in box of 10 pins
- Suits 60mm backset configurations
- Secures oval cylinder within lock body
- Installed beneath cover plate for concealed fixing
- Genuine replacement component
Suitable Uses
- Lockwood 3570 series lock installations
- Replacement of missing or worn retainer pins
- Commercial lock servicing and maintenance
- Cylinder retention in mortice locks
Specifications
Frequently Asked Questions
What does a cylinder retainer pin do?
It secures the oval cylinder within the lock body to prevent movement during operation.
Is this compatible with other backsets?
No, this version is designed specifically for 60mm backset locks.
How many pins are needed per lock?
Each oval cylinder requires one retainer pin.
Additional Information
- Incorrect pin length is a common cause of cylinder misalignment.
- Often replaced during lock servicing or when cylinders are changed.
- Access requires removal of the cover plate during installation.
- Commonly used in commercial environments where Lockwood 3570 locks are standard.
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship for:
- Mechanical components: 25 years
- Electrical and electronic components: 2 years (excluding batteries)
