Rivers 2 Point Self Latching Ext Key & Lever (201 Cylinder) - Dulux Hammertone Black
The Rivers Model D is a high security two point self latching locking device designed specifically for fire door applications. Surface mounted internally and operated externally by key and lever, this lock provides compliant emergency egress while delivering robust multi point security.
Key Features
- Two point self latching locking system.
- External key and lever operation.
- Fire rated up to 4 hours in accordance with AS1905 Part 1.
- Two 32 mm x 10 mm zinc plated locking bars.
- 45 mm throw to each locking point.
- Internal lever rotates 90 degrees to disengage locking bars.
- Scale 7 rating under AS4145.2 testing.
- Finished in Dulux Hammertone Black powder coat.
- Includes 201 six pin cylinder with anti drill disk.
Compatibility
- Suitable for Trafalgar, Pyropanel FR, Pyrolit and Pandor fire rated doorsets.
- Adjustable to suit door widths from 760 mm to 960 mm.
- Surface mounted to the inside of solid core doors.
- Complies with Building Code of Australia emergency egress requirements.
- Suitable for financial institutions, schools, warehouses and retail applications.
Full Specifications
Whats In The Box
- Internal self latching lock body.
- External key and lever assembly.
- 201 six pin cylinder.
- Fixing hardware and locking bar keepers.
Dimension
Frequently Asked Questions
- Is this lock fire rated?
Yes. It is fire rated up to 4 hours in accordance with AS1905 Part 1. - Are these locks handed?
Yes. The lock must be specified as either Left Handed or Right Handed. - Is the 201 cylinder included?
Yes. The external unit is supplied with a 201 six pin cylinder.
Additional Information
- Brought to order item with 6 to 8 week lead time.
- Non returnable product.
- Freight charges apply.
- Long body models required for door widths above 960 mm.
Technical Drawing
