Lockwood Pinnacle Sliding Door Mortice Locks — PI80000 / PI80100 / PI80200
The Lockwood Pinnacle Sliding Door Mortice Lock is engineered for superior performance on sliding aluminium doors. Featuring a single hook bolt with anti-lift and anti-slam protection, it ensures strength, durability, and smooth operation. Available in multiple backsets, the Pinnacle Sliding Door Mortice Lock is a robust choice for modern residential and light commercial applications.
Key Features
- Hook bolt locking with integrated anti-lift protection.
- Anti-slam mechanism prevents bolt damage if door is closed on bolt.
- Supplied with adjustable strike for fine installation tolerance.
- Stainless steel faceplate and robust internal design.
- Keyed alike convenience with other ASSA ABLOY CYL4™ 5-pin systems.
- Backset options: 30mm, 35mm, 40mm.
- Door thickness: 32–45mm.
- Tested to withstand 4kN force entry load and 100,000 latching cycles.
- Compatible with Aria D handle sets (back-to-back or half set).
- Identical routing footprint to Optimum Mortice Locks for simplified installation.
Specifications
- Item Code Family: PI80 Series
- Backsets: 30 mm, 35 mm, 40 mm
- Materials: Stainless steel faceplate, heavy-duty mechanism
- Furniture: Recommended with Aria D handle sets
- Keying: 5-pin fixed cam Euro profile cylinders (ordered separately)
- Finish: Brushed Stainless Steel faceplate supplied
- Fixing Surface: Aluminium sliding doors
Item Code Family — Lockwood Pinnacle Sliding Door Mortice Locks
Accessories & Spares
Suitable Uses
- Sliding aluminium doors requiring robust hook-bolt security.
- Residential doors where anti-lift and anti-slam features are critical.
- Installations needing 4kN entry load resistance and long-cycle durability.
- Projects using ASSA ABLOY CYL4™ systems for one-key convenience.
Additional Information
- Identical routing details to Optimum Mortice Locks for easier specification.
- Available in multiple cylinder configurations: double cylinder, cylinder/turnknob, half cylinder, or half turnknob.
- Faceplate supplied in Brushed Stainless Steel for a clean finish.
- Designed for morticed installation into door edge.
Warranty
- General Warranty: 25 years on mechanical parts and workmanship
- Electrical/Electronic Components: 3 years (excludes PADDE, electric mortice locks & batteries)
- PADDE & Electric Mortice Locks: 5 years
- Keys: 12 months
- Finishes: Everbrass 25 yrs; Stainless/Chrome/Anodised 10 yrs; PVD incl. VIVID 10 yrs; Symmetry 5 yrs; Decorative finishes 2 yrs
Download PDF Resources
|
Lockwood 25 Year Mechanical Warranty (Conditions Apply) |
|
Lockwood Euro Profile Mortice & Twin Bolt Locks — Catalogue |
Lockwood Warranty
Lockwood branded products are covered by manufacturer warranties issued by ASSA ABLOY Australia Pty Ltd. Warranty periods vary by product type, with separate cover for mechanical components, electrical and electronic parts, keys, and finishes.
The summary below sets out the standard warranty structure. All warranty claims are handled by Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries. Full terms and exclusions are set out in the official Lockwood warranty document linked at the base of this page.
Warranty Summary
Finish Coverage Guide
- Everbrass finishes: up to 25 years against corrosion, tarnishing and discolouration.
- Stainless steel, polished stainless steel, chrome plating and anodised finishes: typically up to 10 years.
- PVD and VIVID finishes: typically up to 10 years.
- Symmetry range finishes: typically up to 5 years.
- Decorative finishes (Antique Copper, Architectural Bronze, Oil Rubbed Bronze, Aged Brass, Polished Brass, Satin Brass and related variants): typically up to 2 years against corrosion.
- Unlacquered brass finishes naturally age and change appearance over time. This is not considered a defect.
- Tea staining of stainless steel is not covered where the required cleaning and maintenance have not been followed.
How to Make a Claim
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
- Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries with your proof of original purchase.
- Keep the product securely packed and clearly identified, ready for assessment.
- Where a claim is escalated to the manufacturer, ASSA ABLOY may issue a case number before goods are returned.
- ASSA ABLOY assesses the claim and determines repair, replacement with the same or closest equivalent product, or refund of the purchase price.
Exclusions
- Normal wear and tear.
- Misuse, abuse, accidental damage or use outside published specifications.
- Improper maintenance or failure to follow care instructions.
- Unauthorised modification, repair or use of non-genuine parts.
- Exposure to corrosive environments including coastal air, salt spray, chemicals or pollution.
- Removal, refitment or associated labour charges.
- Products not originally sold in Australia through authorised channels.
Australian Consumer Law
These manufacturer warranties apply in addition to your rights under the Australian Consumer Law. Our goods come with guarantees that cannot be excluded under the ACL. You are entitled to a replacement or refund for a major failure and to compensation for any other reasonably foreseeable loss or damage. Where a failure does not amount to a major failure, you are entitled to have the goods repaired or replaced.
