Dormakaba Narrow Stile Sliding Deadbolt with Escape Lever Only – Satin Chrome
The dormakaba 951 Series swing bolt deadlock is suitable for narrow stile sliding doors. The positive action deadbolt features a hooked bolt design that engages and locks into the latching strike plate when the bolt is thrown.
The deadbolt is locked or unlocked by key (cylinder not included) or a BCA compliant lever. This model is supplied less cylinder and includes strike components and mounting hardware.
Key Features
- 951 Series swing bolt deadlock for narrow stile sliding doors.
- Hooked deadbolt design to engage the latching strike when thrown.
- Locked or unlocked by key (less cylinder) or BCA compliant lever.
- Supplied less cylinder with escutcheon and cam.
- Self latching strike included.
- 29 mm laminated hook bolt.
- 23 mm backset.
- Includes mounting hardware.
- Satin Chrome finish.
Specifications
- Item Code: BO951LSCPLC
- Brand: Dormakaba
- Product Type: Narrow stile sliding swing bolt deadlock (escape lever)
- Handing: Non-handed
- Assembly Form: Less cylinder
- Uses Cylinder/Plug Type: 570 oval
- Backset: 23 mm
- Hook bolt: 29 mm laminated hook bolt
- Case Size: 181 mm (H) x 36 mm (D)
- Aluminium Fabricator Face Plate: 155.5 mm (L) x 25 mm (W)
- Strike Face Plate: 184 mm (L) x 28.5 mm (W)
- Strike Body: 148 mm (L) x 26 mm (D)
- Includes Escutcheons: Yes
- Includes Strike: Yes
- Includes Escape Lever: Yes
- Includes Escape Turn: No
- Includes Turnsnib: No
- Includes Extended Face Plate: No
- Finish: Satin Chrome
What's In The Box
- 1 x dormakaba 951 Series narrow stile sliding deadlock body (less cylinder)
- Escutcheon and cam (as supplied)
- Self latching strike assembly (strike body and strike face plate)
- Mounting hardware
Suitable Uses
- Narrow stile sliding doors requiring a hooked deadbolt for secure strike engagement.
- Doorways requiring key operation with an escape lever function.
- Retrofit or replacement where a 23 mm backset is required.
Dimensions
Frequently Asked Questions
- Does this lock include a cylinder?
No. This model is supplied less cylinder and includes escutcheon and cam as supplied. - Does it include the strike?
Yes. A self latching strike is included, along with strike body and strike face plate. - What cylinder type does it use?
It uses a 570 oval cylinder or plug type as specified.
Additional Information
- Hook bolt locks are commonly selected for sliding doors because the hooked profile helps resist forced separation when engaged in the strike.
- Before ordering the cylinder, confirm key system requirements and compatibility with the specified 570 oval format.
- Confirm strike positioning and clearances so the bolt fully engages the latching strike in the thrown position.
