Dormakaba 6600 Series Square End Plate – Visible Fix – Disabled Turn – Noosa Lever
Dormakaba 6600 series square end plate door furniture designed for internal commercial applications requiring accessible operation. This visible fix plate incorporates a disabled turnsnib and Noosa series lever, commonly specified for amenities and controlled internal spaces using compatible Dormakaba mortice locks.
Key Features
- Square end plate design suited to commercial internal doors.
- Disabled turnsnib provides accessible locking and unlocking.
- Supplied with AS1428.1 compliant Noosa series lever.
- Manufactured from solid 316 grade stainless steel.
Disability Act Compliance
- Designed to meet AS1428.1 requirements for accessible door hardware.
Fire Rated
- Successfully tested up to 4 hours on fire door assemblies in accordance with AS1905.1-2005 Part 1 (doorset dependent).
Specifications
What's In The Box
- 1 x Internal square end plate with disabled turnsnib and Noosa lever
- Fixing screws
Suitable Uses
- Internal amenities and sanitary compartments
- Healthcare, education and commercial buildings
- Doors requiring accessible turn and lever operation
Available Variants
Item Code Family
Download PDF Resources
- Dormakaba 6000 Series Plate Door Furniture
- Dormakaba 6500 & 6700 Series Template and Fitting Instructions
Frequently Asked Questions
Is handing required when ordering?
Yes, the disabled turnsnib is handed and must be selected to suit the door orientation.
Is this suitable for fire doors?
Yes, when installed as part of a compliant doorset, it has been tested up to 4 hours in accordance with AS1905.1.
Does the turnsnib meet accessibility requirements?
Yes, the disabled turnsnib and lever combination is designed to meet AS1428.1 requirements.
Additional Information
- Disabled turnsnib plates are commonly specified for accessible internal door applications.
- Internal and external plates are paired back-to-back to suit the required door function.
- Confirm mortice lock compatibility and handing prior to installation.
