Dormakaba Furniture Screw Standard 6640/00 – Standard Furniture Screws (Box of 2)
The Dormakaba 6640/00 is a standard furniture screw set for plate furniture installations on common commercial door thicknesses. It is specified to suit dormakaba 6400, 6500, 6600, and 6700 series furniture and is supplied as a pair.
The supplied information specifies a 5/32 imperial metal thread that suits dormakaba and compatible stainless steel furniture such as Madinoz.
Key Features
- Standard length furniture screws for common door thicknesses.
- Suits dormakaba 6400, 6500, 6600, and 6700 series plate furniture.
- Specified for doors from 32 mm to 45 mm thick.
- 5/32 imperial metal thread suitable for dormakaba and compatible stainless steel furniture.
- Phillips drive with countersunk head.
- Supplied as a box of two screws.
Specifications
- Item Code: DO664000
- Product Type: Standard furniture screws
- Series Compatibility: Dormakaba 6400, 6500, 6600, 6700 series furniture
- Door Thickness: 32 mm to 45 mm
- Overall Length: 65 mm
- Thread Type: 5/32 imperial metal thread (as specified in supplied information)
- Screw Drive: Phillips
- Screw Head: Countersunk
- Pack Size: 2
- Screw Thread: 11810
What's In The Box
- 2 × Standard furniture screws (6640/00)
Suitable Uses
- Standard plate furniture installations on doors between 32 mm and 45 mm thick.
- Replacement screws for dormakaba 6400, 6500, 6600, and 6700 series furniture.
- Commercial fit-outs and maintenance where a countersunk Phillips furniture screw set is required.
Dimensions
| Dimension | Size |
|---|---|
| Overall Length | 65 mm |
Frequently Asked Questions
- What door thickness range do these standard screws suit?
They are specified to suit doors from 32 mm to 45 mm thick. - Which dormakaba furniture series do these screws suit?
They are specified to suit dormakaba 6400, 6500, 6600, and 6700 series furniture. - How many screws are supplied?
They are supplied as a pack of 2, suitable for back-to-back plate furniture installations.
Additional Information
- Standard furniture screws are typically used where the door thickness is within common commercial ranges and the plates clamp without spacers or thick gaskets.
- If your installation includes packers, acoustic seals, or unusually thick door skins, you may need an extended screw length to maintain secure engagement.
