Brava Urban Tiebolt Entrance Lever Set TE2 Profile – Satin Stainless Steel
The Brava Urban Tiebolt Entrance Lever Set is a domestic grade entrance locking solution featuring a straight lever design, tiebolt fixing, and TE2 profile cylinder. Designed for hinged doors, it provides keyed access from the outside and turn snib operation internally.
Key Features
- Entrance function with key operation externally and turn snib internally.
- Tiebolt fixing system for secure mounting through the door.
- Straight lever design suited to contemporary residential applications.
- TE2 profile cylinder supplied with matching keys.
- Adjustable backset to suit common Australian door preparations.
Specifications
- Product Type: Entrance lever set
- Lock Grade: Domestic
- Fixing Method: Tiebolt
- Key Profile: TE2
- Function: Entrance
- Lever Shape: Straight
- Finish: Satin Stainless Steel
- Door Thickness: 35 mm to 45 mm
- Backset: Adjustable 60 mm to 70 mm
- Lever Projection: 60 mm (may not include turn snib)
- Rose Diameter: 65.5 mm
- Door Handing: Non handed
- Latch: Adjustable 60 mm to 70 mm
- Latch Face Plate: 57 mm x 25 mm
- D Strike: 57 mm x 45 mm x 1.2 mm
What's In The Box
- Pair of entrance levers on roses
- Adjustable latch (60 mm to 70 mm backset)
- TE2 profile cylinder
- 2 x keys
- Mounting hardware (supplied boxed and colour coded)
Suitable Uses
- Residential entrance doors.
- Domestic hinged doors requiring keyed external access.
- Homes using TE2 profile keying systems.
PDF Resources
Frequently Asked Questions
- Is this lever set suitable for external doors?
Yes. This is an entrance function lever set designed for residential external doors where keyed security is required. - Does this suit both left and right hand doors?
Yes. The levers are non handed and can be installed on either left or right hand hinged doors. - Does the set include a cylinder and keys?
Yes. A TE2 profile cylinder and two matching keys are supplied.
Additional Information
- This lever set uses tiebolt fixing, which is commonly preferred for improved rigidity compared to surface fixed levers.
- TE2 profile cylinders are commonly used in domestic keying systems and are suitable for simple keyed alike arrangements.
- The adjustable latch allows installation into doors prepared for either 60 mm or 70 mm backsets without modification.
Brava Warranty
Warranty Summary
How to Make a Claim
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
- Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries first. All warranty claims must be initiated through us - contact Gold Coast Smart Locks via our Returns & Warranty page with your order details and a description of the fault.
- Have your proof of purchase ready. Your original invoice or receipt is required to support any warranty or consumer guarantee claim.
- Describe the fault clearly. Include the product name, model or SKU if known, when the fault was first noticed, and how the product was being used at the time.
- We will assess and progress your claim. Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries will liaise with LSC on your behalf to arrange repair, replacement, or refund as appropriate under the circumstances and applicable law.
Important Notes
Australian Consumer Law.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. These rights apply regardless of any additional warranty terms offered by the manufacturer or distributor.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. These rights apply regardless of any additional warranty terms offered by the manufacturer or distributor.
General warranty exclusions.
Warranty coverage does not extend to damage caused by improper installation, misuse, accidental damage, unauthorised modification, or normal wear and tear. Products must be installed and used in accordance with the manufacturer's documentation and relevant Australian standards.
Warranty coverage does not extend to damage caused by improper installation, misuse, accidental damage, unauthorised modification, or normal wear and tear. Products must be installed and used in accordance with the manufacturer's documentation and relevant Australian standards.
