Brava Urban LE Series Tiebolt Passage Lever Set – Adjustable Backset
The Brava Urban LE Series Passage Lever Set is a domestic-grade, non-locking leverset designed for internal doors where free operation from both sides is required. It features a straight lever profile with tiebolt concealed fixing and an adjustable 60/70 mm backset, making it suitable for new installations and retrofits.
Key Features
- Passage function – both inside and outside levers operate freely at all times.
- Straight lever design to suit the Brava Urban LE Series aesthetic.
- Tiebolt concealed fixing for a clean, secure installation.
- Non-handed levers suitable for left- or right-hand doors.
- Supplied boxed with colour-coded packaging and mounting hardware.
Specifications
What's In The Box
- 2 × Brava Urban LE Series levers on 66.5 mm roses
- Adjustable 60/70 mm tubular latch
- Strike plate
- Fixing screws and mounting hardware
Suitable Uses
- Internal residential doors such as hallways, living areas, and bedrooms.
- Applications requiring free operation from both sides with no locking.
Available Colour Variants
-
Chrome Plate
LE203B -
Matt Black
LEX903B -
Satin Stainless Steel
LE603B
Brava Urban LE Series – Item Code Family
Frequently Asked Questions
Does this lever include a locking mechanism?
No. This is a passage lever set and does not include any locking or keying components.
Is this lever set handed?
No. The levers are non-handed and can be installed on left- or right-hand doors.
Is the latch included?
Yes. An adjustable 60/70 mm tubular latch and strike are supplied.
Additional Information
- This passage lever is commonly specified to match Brava Urban LE Series privacy or entrance levers elsewhere in the same dwelling.
- The adjustable backset allows retrofit into doors prepared for either 60 mm or 70 mm latches.
