Brava Metro Oval Cylinder without Barrel – X, W, Z & R Cams
The Brava Metro 5070 Oval Cylinder without Barrel is a commercial grade oval cylinder body supplied without a plug, intended for use with existing or project-specific restricted key systems. It is supplied with the four most commonly specified cam types to suit a wide range of oval mortice locks.
Key Features
- Oval cylinder supplied without barrel (less plug).
- 6 pin commercial grade cylinder body.
- Pre-loaded with LAB 220 style top pins.
- Compatible with most inline restricted keying systems when fitted with a 570 barrel.
- Supplied with X, W, Z and R (rabbit ear) cam types.
- Supplied boxed.
Specifications
- Item Code: 5070UCPLP
- Cylinder Type: Oval
- Assembly Form: Less plug (no barrel supplied)
- Number of Pins: 6
- Top Pins: LAB 220 style (pre-loaded)
- Cam Types Included: X, W, Z and R
- Lock Grade: Commercial
- Finish: Chrome Plated
- Box Quantity: 20
Suitable Uses
- Projects using existing or restricted key barrels.
- Commercial mortice locks requiring oval cylinder bodies only.
- Master-keyed or restricted systems where barrels are supplied separately.
Brava Metro Oval Cylinders – LW5 Profile (Item Code Family)
Available Colour Variants
-
Chrome Plated
5070UCPLP -
Satin Chrome
5070USCLP
Frequently Asked Questions
Does this cylinder include a key barrel?
No. This product is supplied without a barrel (less plug).
What barrel is typically used with this body?
It is commonly paired with a Brava 570 barrel for restricted key systems.
What cams are supplied?
X, W, Z and R cam types are supplied in the box.
Additional Information
- This product is intended for locksmith and project use.
- Barrel compatibility must be confirmed prior to installation.
- Commonly specified in Australian commercial and institutional sites.
