Lockwood 5782KIT05CD07 — Narrow Mortice Lock Cylinder CD07 Kit
The Lockwood 5782KIT05CD07 is a Selector® 5782 Series narrow mortice lock kit supplied with a cylinder in CD07 configuration. Featuring a 30 mm short backset, this kit is tailored for aluminium and narrow stile doors in commercial and institutional applications. Available in Satin Chrome (SC) and Matt Black (MBK) finishes, it ensures secure deadlatching, fire-rated compliance, and long service life under heavy use.
Estimated Warehouse Dispatch: 6 Days
Non-Returnable Item: This product cannot be returned once purchased
Key Features
- Narrow mortice lock kit with cylinder in CD07 configuration.
- 30 mm short backset designed for aluminium and narrow stile doors.
- Available finishes: Satin Chrome (SC) and Matt Black (MBK).
- Deadlatching bolt with auxiliary latch for added security.
- Compatible with Lockwood 570 oval cylinders, restricted and master key systems.
- In-door configuration using red/green selector under the faceplate.
- Fire rated and compliant with Australian Standards.
Fire Rated
- Tested up to 4 hours on compliant fire door assemblies (AS 1905.1).
Specifications
- Item Code: 5782KIT05CD07
- Variants: 5782KIT05CD07SC (Satin Chrome), 5782KIT05CD07MBK (Matt Black)
- Function: Narrow mortice lock kit with brass furniture and cylinder (CD07).
- Backset: 30 mm short backset.
- Finish Options: Satin Chrome (SC), Matt Black (MBK).
- Door Thickness: 32–50 mm standard; extension kits available.
- Bolt: 15 mm stainless steel latch with auxiliary deadlatch.
- Case: Zinc alloy lock body with stainless steel chassis.
- Compliance: AS4145.2 (Durability D8, Security S7); AS1905.1 (Fire Doors).
What's In The Box
- 1 × Lockwood 5782 mortice lock body (30 mm backset)
- Brass furniture set (finish matched)
- 1 × Cylinder (CD07 configuration, finish matched)
- 1 × Satin Chrome or Matt Black faceplate
- 1 × Satin Chrome or Matt Black strike plate
- Fixing screws
- Installation instructions
Available Finish Options
Satin Chrome
5782KIT05CD07SC
Matt Black
5782KIT05CD07MBK
Selector® 5782 Short Backset Escape Locks — Item Code Family (30 mm Backset)
Selector® 5782 — Accessories & Spares (Short Backset Platform, 30 mm Backset)
.
Warranty
- Lockwood 25 Year Mechanical Warranty covers mechanical components and workmanship under normal use and correct installation.
- Electronic and electrical components are covered for 3 years (PADDE & electric mortice locks 5 years, batteries excluded).
- Keys are covered for 12 months.
- Finish warranty varies by finish type and exposure — e.g. Everbrass 25 years; Stainless/Chrome/Anodised 10 years; PVD/VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
- Warranty excludes misuse, improper installation, modification, or failure to maintain as specified.
