Lockwood 225 Artefact Interior Rectangular Plate - DDA Accessible Turnknob & Lever 96 | Marine Grade & Satin Stainless Steel
The Lockwood 225 Series Artefact Interior Rectangular Plate with DDA Accessible Turnknob and Lever 96 combines a DDA-accessible lever-form turnknob meeting AS1428.1-2009 with a DDA-compliant Lever 96 for accessible interior locking and lever-operated latch release.
This is a HANDED function - specify Left or Right Hand at order. Available in 316 Marine Grade and Satin Stainless Steel. Note: replace NN with NS in the cylinder code when ordering with the Selector 3770 Series. Visible fixings (screws not included). Pairs with the 224 Series exterior plate.
Estimated Warehouse Dispatch
Usually ships in 11 business days
Usually ships in 11 business days
Special Order - Non-Returnable Item
Please confirm handing and suitability. HANDED function - L or R must be specified.
Please confirm handing and suitability. HANDED function - L or R must be specified.
Available Finish Options
316 Marine Grade
MG- Satin Stainless Steel
SS
Available in left and right hand.
Fire Rated
- Fire rated up to 4 hours - AS1905.1:2005. Fire performance is dependent on doorset type and configuration. Compliance is system-based and limited by the FRL of the complete doorset assembly.
Disability Act Compliance (DDA)
- The DDA-accessible turnknob meets the requirements of AS1428.1-2009, Design for Access and Mobility, providing an accessible interior turn operation for people with limited hand strength or dexterity.
- Lever compliance also meets AS1428.1-2009 where applicable. Compliance relates to hardware design only and does not imply full building compliance.
Key Features
- Rectangular 162 x 50mm interior plate with square ends - Lockwood Artefact 225 Series
- DDA Accessible Turnknob and Lever (Function 39) - HANDED function
- DDA lever-form accessible turnknob - meets AS1428.1-2009
- Lever 96 - AS1428.1-2009 compliant. Length 124mm, Projection 55mm, Finger Clearance 35mm.
- 316 Marine Grade and Satin Stainless Steel. Visible fixings. Fixing screws not included.
- Note: replace NN with NS when ordering with Selector 3770 Series.
- Fire rated to 4 hours - AS1905.1:2005. Level D8 (500,000 cycles). 25-year mechanical warranty.
Full Specifications
Item Codes
Plate Dimensions & Technical Drawings
Plate dimension drawing - 162 x 50mm rectangular profile with square ends and cross-section details.
Standards and compliance - fire rating, Level D8 cycling test and anti-corrosion.
Functions diagram - full range of 224/225 Series plate configurations.
Ordering procedure for the 224/225 Series - plate type, function, engraving, cylinder, lever, handing and finish codes.
Helpful Tips
- Handing: Determined by which side the hinges are on when facing the door from outside. Left hand = hinges on left.
- Selector 3770 Series: For use with Selector 3770, replace NN with NS in the cylinder type code.
- DDA turnknob: Function 39 uses an accessible lever-form turnknob that is easier to operate for people with limited hand strength or dexterity.
- Fixing screws not supplied: The visible fixing screws for this interior plate must be ordered separately.
- Interior plate - pairs with 224 Series: This is the inside face plate with visible fixings. It must be paired with a 224 Series exterior plate (rectangular, concealed fixings). Fixing screws not included.
- Door thickness: 35-45mm as standard. For 45-55mm order SP2000-208 long fixing screws. Maximum 65mm with appropriate accessories.
- Non-returnable: Confirm finish and handing before ordering.
Lockwood Warranty (Australia)
Mechanical: 25 years. Electrical/electronic: 2 years (excl. batteries).
Mechanical: 25 years. Electrical/electronic: 2 years (excl. batteries).
Finish Warranty Guide:
- Stainless Steel: Up to 10 years
- 316 Marine Grade: Up to 10 years
Cosmetic finishes, batteries, normal wear and tear, misuse, unauthorised modification, corrosion and labour or freight costs are excluded.
This warranty operates in addition to rights under the Australian Consumer Law.
