Schlage Breeze Keypad Controller to suit Omnia Locks BLE IP66 - Black
Key Features
- Keyless access controller designed for Schlage Omnia or Schlage eGO smart locks.
- Relay control output for locking devices or integrated systems.
- Access control device featuring keypad, card reader and Bluetooth app access.
- Manage access via Schlage Breeze or Schlage Breeze Hotel software.
- IP66 rated for improved protection in exposed installations.
Specifications
| Specification | Details |
|---|---|
| Item Code | SCEOMKPC |
| Material | Aluminium frame / tempered glass panel |
| Communication | Bluetooth 4.1 |
| Standby Current | 15 mA |
| Operating Current | 1 A (maximum) |
| Power Supply | 9 to 16 V |
| Access Method | PIN, keytags/cards, Breeze app |
| BLE Apps | Schlage Breeze, Schlage Breeze Hotel, Schlage Breeze Guest |
| Number of Users | Unlimited users via app (BLE) |
| Keytags/Cards | Up to 200 |
| PIN Code | Custom: 150, Scheduled: 150, Length: 4 to 9 digits |
| Unlocking Time | 1.5 s (configurable in Schlage Breeze app) |
| IP Rating | IP66 |
| Dimensions | 79 x 129 x 15 mm |
What's In The Box
- 1 x Schlage Keypad Controller unit.
Suitable Uses
- Keyless entry control where PIN, card or app access is required.
- Sites using Schlage Breeze or Schlage Breeze Hotel for access management.
- Relay controlled door hardware such as electric strikes and magnetic locks.
- Outdoor or exposed locations where IP66 rating is beneficial.
Dimensions
| Measurement | Size |
|---|---|
| Width | 79 mm |
| Height | 129 mm |
| Thickness | 15 mm |
PDF Resources
Frequently Asked Questions
- How is access managed on site?
Access can be managed using Schlage Breeze or Schlage Breeze Hotel software, with keypad and credential support. - What access methods does it support?
PIN entry, keytags/cards and the Breeze app are supported. - Is it suitable for outdoor installation?
It has an IP66 rating, which provides improved protection for exposed locations.
Additional Information
- Relay output allows integration with a range of locking devices and access control workflows.
- Bluetooth connectivity supports app based management through the supported Breeze applications.
Technical Drawing
