LOX Single Mini Mount Electro Magnetic Lock - Silver
The LOX CCW series mini electro magnetic lock is designed to secure small sliding doors such as lockers, cupboards and cabinets. Its compact design allows installation where space is limited while still providing a holding force of up to 180 kg.
Key Features
- Compact micro electro magnetic lock
- Designed for sliding doors, lockers and cupboards
- Holding force up to 180 kg
- Dual voltage operation 12V DC or 24V DC
- Flush or surface mounting options available
- Built in MOV surge protection
- No moving mechanical parts
- Satin anodised aluminium housing
- Zinc plated electromagnetic body
- Grain orientated silicone steel armature plate
Compatibility
- Sliding doors
- Cabinet doors
- Locker doors
- Small cupboards
- Light duty access control installations
Full Specifications
| Brand | LOX Locking |
| Maglock Type | Mini Electro Magnetic Lock |
| Holding Force | 180 kg |
| Working Voltage | 12 / 24 V DC |
| Current | 350 mA at 12 V DC / 175 mA at 24 V DC |
| Monitoring | Non Monitored |
| Fire Rated | No |
| Finish | Satin Anodised |
| Magnet Size | 202 mm (L) x 34.4 mm (H) x 21.5 mm (D) |
| Armature Plate Size | 130 mm (L) x 32 mm (H) x 9 mm (D) |
What's in the Box
- Mini electro magnetic lock body
- Armature plate
- Mounting hardware
- Installation fixings
Dimensions
Magnet body: 202 mm length x 34.4 mm height x 21.5 mm depth.
Armature plate: 130 mm length x 32 mm height x 9 mm depth.
Frequently Asked Questions (FAQ)
- Where is this mini maglock typically used?
This compact magnetic lock is commonly used on lockers, cabinets, cupboards and other small sliding doors.
- Does this maglock require a specific power supply?
The lock supports both 12V DC and 24V DC power supplies.
- Is this lock monitored?
No. This mini magnetic lock is a non monitored model.
Additional Information
- Mini maglocks are ideal where standard sized magnetic locks are too large for the installation space.
- The absence of moving mechanical parts reduces wear and increases reliability.
- Commonly used in lockers, cabinets, display cases and small secure storage doors.
Warranty
- Manufacturer warranty applies to defects in materials and workmanship.
