LOX LMML2400LZ Inward Opening Mechanical Electro Magnetic Lock Includes L and Z Bracket Satin Anodised
The LOX LMML2400LZ Mechanical Electro Magnetic Lock is a slimline inward opening solution designed for installations where restricted head height or narrow door frames prevent the use of standard magnetic locks.
Key Features
- Slimline design approximately 75 percent smaller than a standard 600 kilogram magnet.
- High holding force up to 1000 kilograms.
- Operates under side load pressure up to 70 kilograms.
- Dual voltage 12 or 24 Volt direct current.
- Full monitoring including Lock Status Sensor, Door Status Sensor and Early Warning alarm.
- Supplied with L and Z bracket.
- 4 hour fire rated.
Fire Rated
- Rated to 4 hours when installed as part of an approved fire door assembly.
Specifications
- Item Code: LMML2400LZ
- Brand: LOX
- Holding Force: 1000 kilograms
- Working Voltage: 12 or 24 Volt DC
- Current Draw: 350 milliamp at 12 Volt DC, 175 milliamp at 24 Volt DC
- Monitoring: Lock Status Sensor, Door Status Sensor, Early Warning alarm
- Finish: Satin Anodised
- Fire Rating: 4 hours
What's In The Box
- LOX LMML2400 lock body
- Armature plate
- L bracket
- Z bracket
- Anti tamper bracket
- Fixing hardware
Suitable Uses
- Commercial access control installations
- Fire rated door assemblies
- Narrow aluminium door frames
- Single inward opening hinged doors
Dimensions
| Component | Length | Height | Depth |
|---|---|---|---|
| Main Lock Body | 218 mm | 36 mm | 30 mm |
| Armature Plate | 174 mm | 30.5 mm | 12.5 mm |
PDF Resources
Frequently Asked Questions
- Is this lock suitable for fire rated doors?
Yes. The LMML2400 Series is rated up to 4 hours when installed as part of an approved fire door assembly. - Can the lock release under door pressure?
Yes. It is capable of releasing with up to 70 kilograms of side load applied to the door. - Does this model include monitoring outputs?
Yes. It includes Lock Status Sensor, Door Status Sensor and Early Warning alarm outputs for integration with access control systems.
Additional Information
- This is a single door mechanical electro magnetic lock.
- Monitoring outputs allow integration with access control systems.
- Installation must comply with local fire regulations.
