LOX Flush Mount Electro Magnetic Lock Slimline 280kg Monitored – Silver
The LOX LEM3500FM is a flush mount electro magnetic lock designed primarily for securing sliding doors. This slimline monitored magnetic lock delivers a holding force of up to 280kg and provides reliable lock status monitoring for integration with access control systems.
Key Features
- Single flush mount magnetic lock.
- Designed for sliding door applications.
- Dual voltage 12V DC or 24V DC operation.
- Integrated lock status monitoring sensor.
- Holding force up to 280kg.
- MOV surge protection.
- Slimline satin anodised aluminium housing.
- Guaranteed no residual magnetism.
Specifications
| Specification | Details |
|---|---|
| Item Code | LEM3500FM |
| Brand | LOX |
| Working Voltage | 12/24 V DC |
| Current | 500mA @ 12V / 250mA @ 24V |
| Holding Strength | 280 kg |
| Monitoring | Monitored (Lock Status Sensor) |
| Fire Rated | No |
| Configuration | Single |
| Finish | Satin Anodised Aluminium |
What's In The Box
- LOX LEM3500FM flush mount magnetic lock body
- Armature plate
- Mounting hardware
Suitable Uses
- Sliding door security applications.
- Commercial access control systems.
- Internal secure areas requiring monitored magnetic locking.
Dimensions
| Component | Measurement (mm) |
|---|---|
| Magnet Body | 238 (L) x 48 (H) x 25 (D) |
| Armature Plate | 185 (L) x 38 (H) x 12 (D) |
Frequently Asked Questions
- Is this lock monitored?
Yes. The LEM3500FM includes a lock status monitoring sensor. - What voltage does it operate on?
It operates on 12V DC or 24V DC. - What type of doors is it designed for?
It is primarily designed for sliding door applications.
Additional Information
- Default operating voltage is factory set to 24 volts.
- Suitable for integration with commercial access control systems.
Technical Drawing
.
