Dormakaba ED22MF Panic Exit Device – Mortice Lock – Fire Rated
Key Features
- Panic exit device designed to operate with MS2 mortice lock.
- Provides secure mortice locking with single action emergency egress.
- Horizontal touch pad operation.
- Supplied complete with MS2ED mortice lock.
- Standard 1060 millimetre length, field sizable to 645 millimetres minimum.
- Suits door thickness 35 to 50 millimetres.
- Mounting plates and through-fixing screws included.
- Field selectable handing.
- Fire rated for use on compliant door assemblies.
Fire Rated
- Successfully tested up to 4 hours on fire door assemblies in accordance with AS1905.1:2005 Part 1, depending on door set configuration.
Specifications
- Item Code: ED22MFSSS
- Series: ED22MF
- Function: Panic exit with mortice lock
- Lock Type: MS2ED mortice lock included
- Device Length: 1060 millimetres (field sizable to 645 millimetres minimum)
- Door Thickness: 35 to 50 millimetres (standard)
- Handing: Field selectable
- Dogging: No
- Finish: Satin Stainless Steel
- Fire Rated: Yes, up to 4 hours (depending on door set)
What's In The Box
- ED22MF panic exit device assembly
- MS2ED mortice lock
- Mounting plates
- Through-fixing screws and installation hardware
Suitable Uses
- Fire rated doors requiring mortice lock security with panic egress.
- Commercial buildings, offices, and institutional exits.
- Doors requiring a robust mortice lock rather than surface latch exit devices.
Dimensions
Frequently Asked Questions
- Is this device suitable for fire doors?
Yes. It is fire rated up to 4 hours on compliant fire door assemblies, depending on the door set configuration. - Does this include the mortice lock?
Yes. This model is supplied complete with the MS2ED mortice lock. - Can the bar be cut down on site?
Yes. The 1060 millimetre bar can be field sized down to a minimum of 645 millimetres.
Additional Information
- Mortice exit devices are commonly specified where higher security or external lever trim is required.
- Correct mortice lock positioning and door preparation are critical for smooth operation.
- On fire doors, ensure all hardware and seals remain compliant after installation or field sizing.
