Lockwood EMZ8SP-PCBM Spare PCB (Monitored) for EMZ8 Maglocks
The EMZ8SP-PCBM is the genuine monitored spare PCB for Lockwood Z-Series EMZ8 electromagnetic locks. Replace a failed circuit board to restore instantaneous release electronics and status monitoring (door position and bond/lock state on monitored models). Designed for EMZ8-SM monitored variants; not suitable as an upgrade for non-monitored EMZ8-SN units.
Warranty
- 5 Year Tricare Warranty (Padde Series)
- Lockwood 25 Year Mechanical Warranty (Conditions Apply)
Key Features
- Genuine Lockwood spare PCB for EMZ8-SM monitored maglocks
- Restores instantaneous release (zero residual magnetism)
- Restores reed door monitoring and hall/bond lock status outputs
- Dual-voltage 12/24 VDC compatible (as per lock)
- Drop-in replacement PCB — minimises downtime
- ESD-sensitive component — handle with proper precautions
Specifications
- Part Number: EMZ8SP-PCBM
- Compatibility: Lockwood Z-Series EMZ8 monitored models (EMZ8-SM)
- Not for: EMZ8-SN non-monitored (board will not add monitoring)
- Supply: 12/24 VDC as per host lock wiring
- Functions Restored: Instant release, reed door position, hall/bond status (on monitored models)
- Installation: Qualified technician recommended; observe static protection
- Package: PCB assembly only — magnet body and armature not included
What's In The Box
- EMZ8SP-PCBM monitored spare PCB
- Connector pack (as supplied)
Suitable Uses
- Field replacement for EMZ8-SM monitored maglocks
- Restoring monitoring outputs for access control integration
- Minimising downtime in high-traffic or critical access doors
Dispatch & Returns
- Estimated Warehouse Dispatch: 2-4 business days when in stock (call to confirm)
