Dormakaba MS2602 Classroom Lock Kit with 6600 Square End Plate Furniture and Cam

dormakaba entrance door kit with stainless steel furniture.

Ideal for commercial use.

The mortice lock kit includes the following:

• Mortice lock-DKMS2602SSS.
• External & Internal handles-DO6600/30SSS/DO6606/30SSS.
• 'L' cam.

Cylinders not included.

BCA AS1428.1 -2009 compliant leversets.

Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

Mortice lock

• DKMS2602SSS primary mortice lock.
• Case, cover & faceplate constructed from 304 grade stainless steel.
• Operated by key or handle outside or by handle inside.
• 60 mm backset as standard.
• 14 mm stainless steel reversible latch bolt.
• Anti-lockout function built-in.
• Easily adapted to most functions.
• Suits door thickness 32-50 mm.
• Supplied less cylinder.
• Compatible to most restricted keying systems.
• Compatible with most electric strikes.
• SCEC approved (SL3).
• MS2 M Series lock conforms to level SL8 (Physical Security) in accordance with Australian lock standard AS4145.2-2008.
• MS2 M Series lock conforms to level D8 (Durability) in accordance with Australian lock standard AS4145.2-2008.
• Fire rated up to 4 hours.
• Finished in stainless steel.

Furniture

• Rectangular exterior square end plate with oval cylinder hole.
• Rectangular interior square end plain plate.
• 30 series levers.
• Plate size 165 x 45 x 10 mm.
• Plates are designed to fit back to back.
• Suits door thickness from 32 to 50 mm.
• External plates supplied with fixing screws.
• Screw fixing centres 148.25 mm.
• Disabled access AS1428.1 compliant lever.
• Fire rated.
• Finished in satin stainless steel.
