Briton Panic Bar 376E Single Panic Bolt – Silver
The Briton 376E Series is an economical range of push bar panic devices designed for commercial applications. This single vertical panic bolt is suitable for aluminium, hollow metal and timber swinging doors, providing reliable emergency egress while helping prevent unauthorised entry.
Key Features
- Vertical panic bolt device for single door applications.
- Reversible design with two point locking.
- Anti thrust device to prevent unauthorised retraction of the latchbolt.
- Adjustable top and bottom shoots with easy clean socket.
- Provides security against unauthorised entry.
Fire Rated
- Successfully tested up to 2 hours on fire door assemblies.
- Tested in accordance with AS 1905.1:2005 Fire Resistant Doorsets.
- Fire rating depends on the complete doorset configuration.
Specifications
- Product Type: Single vertical panic bolt
- Door Type: Timber, aluminium or hollow metal
- Maximum Door Width: 1300 mm
- Maximum Door Height: 2500 mm
- Minimum Stile Width: 78 mm with 13 mm rebates, 90 mm with 25 mm rebates
- Locking Mode: Vertical
- Dogging: No
- Finish: Silver
What's In The Box
- Briton 376E single vertical panic bolt assembly
- Adjustable top and bottom shoots
- Standard strike
- Timber fixing screws
Suitable Uses
- Single commercial doors requiring compliant panic egress.
- Emergency exits on timber, aluminium or metal doors.
- Fire rated door assemblies where approved as part of the doorset.
Frequently Asked Questions
- Is this suitable for fire doors?
Yes. The Briton 376E has been tested up to 2 hours as part of a compliant fire doorset. - Does this device include a dogging function?
No. This model does not include a dogging or holdback function. - What door sizes does this suit?
It is suitable for doors up to 1300 millimetres wide and 2500 millimetres high.
Additional Information
- The anti thrust device helps reduce the risk of forced attack by preventing external retraction of the latchbolt.
- Correct door preparation and alignment are critical for reliable operation of vertical panic bolts.
- For double door applications, a matching companion device should be specified.
