Brava Urban Double Cylinder Deadbolt – TE2 Profile
The Brava Urban Double Cylinder Deadbolt – TE2 Profile is a domestic-grade deadbolt designed for residential hinged doors where keyed locking is required from both sides.
This model uses a Silca TE2 keyway with a 5-pin cylinder assembly, making it suitable for standard domestic keying where restricted systems are not required. An adjustable 60 mm / 70 mm backset allows compatibility with common Australian door preparations.
Key Features
- Double cylinder operation – key access required on both sides.
- Domestic grade deadbolt for residential hinged doors.
- Silca TE2 keyway with 5-pin cylinder assembly.
- Solid, saw-resistant deadbolt.
- Adjustable backset suits 60 mm or 70 mm installations.
Specifications
What’s in the Box
- 1 × External keyed cylinder
- 1 × Internal keyed cylinder
- 1 × Solid deadbolt assembly
- Adjustable latch (60 mm / 70 mm)
- Strike plate
- 2 × door thickness spacers
- Mounting screws and fixing hardware
- 2 keys included
Available Colour Variants
-
Antique Copper
210BAC -
Polished Brass
210BPB -
Polished Stainless Steel
210BPSS -
Satin Stainless Steel
210BSSS
Brava Urban Deadbolts – Item Code Family
Frequently Asked Questions
Is a double cylinder deadbolt suitable for residential use?
It can be used on residential doors, however local building and fire egress requirements should be checked, as keyed access is required from both sides.
Can this deadbolt be keyed alike to other locks?
This TE2 version is intended for standard domestic keying and is not compatible with restricted key systems.
Does this suit timber and aluminium doors?
Yes, provided the door is hinged and falls within the specified thickness range.
Additional Information
- Double cylinder deadbolts are often specified where internal thumbturns are not permitted.
- Installers should confirm compliance with local regulations before fitting to exit doors.
- The TE2 keyway is commonly used in domestic settings where restricted key control is not required.
- Door preparation accuracy is important to ensure correct bolt alignment and smooth operation.
