ABUS 72IB40 Rekeyable Padlock - Red (Keyed Alike 001)
The ABUS 72IB40 is a compact, rekeyable aluminium padlock designed for system and master key applications. It features a 40 mm colour anodised aluminium body and a stainless steel shackle for improved corrosion resistance. This version is supplied keyed alike to code 001 and finished in red for visual identification within keyed systems.
Key Features
- Rekeyable design suitable for master key and large keyed-alike systems.
- 40 mm colour anodised aluminium body for corrosion resistance and colour coding.
- Stainless steel shackle for improved resistance in damp or corrosive environments.
- Compatible with ABUS interchangeable cylinder systems.
- Optional stopper ring available for key-retaining operation.
Specifications
- Item Code: 72IB40REDKA001
- Series: ABUS 72
- Body Material: Aluminium (colour anodised)
- Body Width: 40 mm
- Shackle Material: Stainless steel
- Shackle Diameter: 6.5 mm
- Vertical Shackle Clearance: 27 mm
- Horizontal Shackle Clearance: 20 mm
- Keying: Keyed alike (001)
- Rekeyable: Yes
- Keyway: Silca LW3
- Finish: Red
- Keys Supplied: None
What's In The Box
- 1 × ABUS 72IB40 rekeyable padlock body
- Interchangeable cylinder keyed alike to 001
- No keys supplied
Suitable Uses
- Facilities operating master key systems.
- Utilities, councils, schools, and commercial sites.
- Applications requiring colour-coded access control.
Standard vs Long vs Concealed Shackle Chooser
| Shackle Type | Best For | Trade-Off |
|---|---|---|
| Standard Shackle (This model) | Compact system installations | Limited reach |
| Long Shackle | Deeper or offset fittings | More exposed to leverage |
| Concealed Shackle | Higher attack resistance | Reduced clearance flexibility |
ABUS 72 Series – Item Code Family
Download PDF Resources
|
ABUS Padlocks Catalogue |
Additional Information
- The ABUS 72 Series is commonly used by locksmiths for expandable master key systems.
- Stainless steel shackles are preferred in damp or wash-down environments.
- Colour anodised bodies assist with zone identification and access control.
- Stopper rings are used where key retention is required for safety or process control.
