Suprema FaceStation F2 Fusion Multimodal IP65 Facial Recognition and RFID Reader - Silver/Black
The Suprema FaceStation F2 (FSF2AB) is a fusion multimodal facial recognition terminal that combines fast face authentication with an RFID reader for flexible credential options. It is designed for access control and time and attendance sites where contactless recognition, anti-spoofing and a weather-resistant device are required.
Key Features
- Fusion multimodal terminal combining facial recognition and RFID card reading.
- Walk-through face recognition for smoother user flow (no need to stand still in a fixed zone).
- Recognition distance range: 50 cm to 130 cm.
- Infrared recognition supports face authentication under dim lighting.
- IP65 rated housing for dust and water resistance in exposed locations.
- 7 inch display for clear prompts and on-device user interaction.
Specifications
- Item Code: FSF2AB
- Brand: Suprema
- Finish: Silver/Black
- Authentication: Facial recognition
- RFID: Yes
- Card Format: EM Prox 125 kHz, HID 125 kHz, Mifare, DESFire 2K
- Working Voltage: 12 Vdc to 24 Vdc
- Internet Protocol Rating: IP65
- Wiegand Output: Yes
- RS-485 Interface: Yes
- Relay Outputs: 1
- RJ45 Ethernet Interface: Yes
- Accepts Smart Phone Near Field Communication and/or Bluetooth Low Energy: Yes
- Diagonal Screen Size: 7 inches
- Screen Resolution: 800 x 1280
What's In The Box
- Suprema FaceStation F2 terminal (FSF2AB)
Suitable Uses
- Commercial access control where contactless facial recognition is preferred.
- Sites needing a weather-resistant reader for semi-exposed locations (for example, sheltered external entry points).
- Time and attendance installations requiring on-device screen guidance and fast throughput.
Dimensions
Suprema FaceStation Series - Item Code Family
Frequently Asked Questions
- Is this suitable for outdoor installation?
The device housing is rated IP65 for dust and water resistance. For best results, mount it where it is not directly exposed to constant driving rain and ensure cable entry points are sealed correctly. - What credentials can it read besides facial recognition?
This model includes an RFID reader supporting EM Prox 125 kHz, HID 125 kHz, Mifare and DESFire 2K. - What is a common installation mistake to avoid?
Avoid mounting it where strong backlighting or reflections point directly at the camera. Positioning and height setup matter for consistent face capture, especially in busy entry lanes.
Additional Information
- Face recognition terminals typically perform best when installed at a consistent mounting height with a clear approach path (avoid sharp turn entries where users present side-on).
- In mixed-credential sites, RFID is commonly used as a fallback for visitors, PPE-heavy areas, or where face capture is restricted.
- Where RS-485 is used for downstream devices, plan cable routes early to avoid rework and keep terminations accessible for commissioning.
