Suprema FaceStation 2 Facial Recognition Terminal - FS2D
The Suprema FaceStation 2 is a high performance facial recognition terminal designed for access control and time attendance applications. It combines face authentication, fingerprint recognition and RFID credential support in a single IP connected device.
Key Features
- Facial recognition access control terminal with live face detection.
- Supports EM 125kHz and 13.56MHz MIFARE, MIFARE Plus, DESFire and FeliCa cards.
- Accepts mobile credentials via Near Field Communication (NFC).
- High speed 1.4 GHz quad core processor.
- Supports up to 30,000 users in one to one mode.
- Integrated fingerprint and RFID reader.
- Ethernet connectivity for networked access control systems.
- Intercom function supported.
Specifications
- Item Code: FS2D
- Finish: Black
- User Capacity (1:1): 30,000 users
- User Capacity (1:N): 3,000 users
- Maximum Faces per User: 5
- Text Log Capacity: 5,000,000 events
- Image Log Capacity: 50,000 events
- Processor: 1.4 GHz quad core
- Memory: 8 GB flash, 1 GB RAM
- Display: 4 inch colour TFT LCD
- Operating Temperature: -20°C to 50°C
- Operating Humidity: 0 to 80 percent non condensing
- Network: 10/100 Mbps Ethernet
- RS-485: 1 channel host or slave selectable
- Wiegand: 1 input or 1 output
- USB: USB 2.0 host
- Power Supply: 24 Volt direct current
- Tamper: Supported
What's In The Box
- Suprema FaceStation 2 terminal
- Mounting bracket
- Fixing hardware
Suitable Uses
- Commercial access control entry points.
- Corporate offices and industrial facilities.
- Time and attendance systems.
- High traffic doors requiring fast biometric identification.
Dimensions
Suprema FaceStation Series - Item Code Family
Frequently Asked Questions
- Can this unit be installed outdoors?
No. The FS2D model does not include ingress protection and is intended for indoor installations. - Does it support both facial recognition and cards?
Yes. It supports face authentication as well as EM and MIFARE DESFire card credentials. - Is this a standalone access control system?
It is typically used with Suprema access control software or controllers for full system functionality.
Additional Information
- Commonly specified for corporate and high traffic commercial entry points.
- Facial recognition reduces wear associated with high volume keypad or card use.
- Indoor installation is recommended as the unit is not rated for weather exposure.
