Salto XS4 Mini Escutcheon for Australian Mortice - HSE - Z Handles - Satin Stainless Steel
Key Features
- Standalone electronic escutcheon with Hardware Security Element (HSE).
- Designed to suit Australian mortice locks.
- Z handle set with accessibility compliant lever design.
- Universal spindle kit included.
- Supports RFID, BLE, and NFC credentials.
- Hardened anti-drill protection.
- Concealed fixing screws.
Specifications
| Specification | Details |
|---|---|
| Item Code | UM150ZRIMBU6 |
| Series | XS4 Mini |
| Escutcheon Type | Australian mortice version |
| Security Technology | Hardware Security Element (HSE) |
| Door Thickness | 32mm to 48mm |
| Spindle Type | 7.6mm and 8mm square |
| Handle Type | Z handles |
| Handle Rotation | 45 degrees |
| Compliance | AS1428.1 |
| Finish | Satin Stainless Steel |
What's In The Box
- External escutcheon with reader.
- Internal escutcheon.
- Z handle set.
- Universal spindle kit.
- Fixing components.
- Finish matched cover plate.
Suitable Uses
- Commercial office doors using Australian mortice locks.
- Retrofit access control upgrades.
- Education, healthcare, and government facilities.
- Doors requiring AS1428.1 compliant levers.
Dimensions
| Measurement | Size |
|---|---|
| Height | 127mm |
| Width | 58.5mm |
| Depth | 22.5mm |
Frequently Asked Questions
- Does this suit Australian mortice locks?
Yes. It is designed specifically for Australian mortice lock installations. - Does it require wiring through the door?
No. It is a standalone escutcheon with wireless capability depending on system setup. - Which spindle sizes are supported?
Supports both 7.6mm and 8mm square spindles.
Additional Information
- Metal escutcheon suited to high traffic commercial environments.
- Mortice locks with maximum 4 degree pre-turn recommended.
- Compatible with Salto SPACE and KS platforms.
