Salto GEO Wireless Camlock 1-15mm Door with 40mm Cam - Satin Chrome
The Salto G9CL119M40CSBAW is a wireless electronic camlock designed for cabinets and lockers with 1 mm to 15 mm door thickness. Supplied with a 40 mm cam (straight and stepped options), it integrates with the Salto XS4 platform and supports Salto Virtual Network capability for managed access in locker and cabinet applications.
Key Features
- Wireless electronic camlock for cabinets and lockers.
- Suits door thickness from 1 mm to 15 mm.
- Supplied with 40 mm straight and stepped cam options.
- Integrated with the Salto XS4 platform.
- Salto Virtual Network capability via Salto SVN technology.
- Encrypted communication between carrier and cylinder.
- Dual colour light indication for access status.
- Removable knob for battery access and servicing.
Specifications
What's In The Box
- 1 x Salto GEO wireless electronic camlock
- 1 x 40 mm straight cam
- 1 x 40 mm stepped cam
- Adjustment accessories
- 1 x CR2 battery
Suitable Uses
- Metal cabinets and lockers.
- Electronic access control for storage units and secure compartments.
- Retrofit replacement for mechanical camlocks (subject to door prep and cam requirements).
- Locker and cabinet systems requiring managed access.
Dimensions
Frequently Asked Questions
- What door thickness does this camlock suit?
It is designed for cabinet or locker doors from 1 mm to 15 mm thick. - Does this include both cam styles?
Yes. It is supplied with a 40 mm straight cam and a 40 mm stepped cam. - What credentials does it support?
It is compatible with MIFARE and DESFire contactless credentials.
Additional Information
- Cam selection matters: use the straight or stepped cam depending on the cabinet frame and latch engagement required.
- When retrofitting from a mechanical camlock, confirm the existing hole preparation and cam rotation match your cabinet design.
- Battery access is via the removable knob, which can simplify scheduled maintenance across large locker banks.
