Risco Wireless Vitron Acoustic Glassbreak Detector with Swivel Bracket - White
The Risco Vitron wireless acoustic glassbreak detector provides perimeter protection by detecting the sound signature of breaking glass. It uses dual frequency pattern recognition to analyse both low and high frequency signals, helping distinguish real glass break events from false alarms.
Designed for residential and commercial applications, the detector is supplied with a swivel bracket for wall or ceiling mounting, allowing optimal positioning for reliable coverage.
Key Features
- Wireless acoustic glassbreak detector.
- Dual frequency pattern recognition.
- Detects plate, tempered, laminated and wired glass.
- Up to 9 metre detection range.
- Wall and front cover tamper protection.
- Supplied with swivel bracket for wall or ceiling mounting.
- Long-life lithium battery operation.
- Compatible with multiple Risco wireless systems.
Specifications
- Item Code: RWT6G043300C
- Product Type: Acoustic glassbreak detector
- Finish: White
- Wireless Connectivity: Yes
- Detection Technology: Dual frequency acoustic analysis
- Detection Range: Up to 9 metres
- Battery Type: 1 × CR123 3 Volt lithium
- Typical Battery Life: Up to 3 years
- Current Consumption: 22 microamp standby
- Frequency: 433.92 megahertz
- Supervision Transmission: 15 or 65 minutes
- Wireless Range (open air): Up to 300 metres
- Operating Temperature: 0 to 50 degrees Celsius
- Dimensions: 87 × 50.7 × 28.6 millimetres
- Compatibility: Risco Agility, WisDom, ProSYS, LightSYS and Nova systems
What's In The Box
- 1 × Risco wireless glassbreak detector
- 1 × Swivel mounting bracket
- 1 × CR123 lithium battery
- Installation instructions
Suitable Uses
- Perimeter protection of windows and glazed doors.
- Residential security installations.
- Commercial shopfront and office glazing protection.
- Applications where early glass break detection is required.
Dimensions
| Measurement | Value |
|---|---|
| Height | 87 mm |
| Width | 50.7 mm |
| Depth | 28.6 mm |
PDF Resources
Frequently Asked Questions
- What types of glass does this detector support?
It detects common glass types including plate, tempered, laminated and wired glass. - How far from the glass can it be installed?
The detector has a typical coverage range of up to 9 metres, depending on installation conditions. - Is the mounting bracket included?
Yes. A swivel bracket is supplied for wall or ceiling mounting.
Additional Information
- Glassbreak detectors are commonly used to provide early warning before an intruder enters the premises.
- Correct positioning facing the protected glass area is important for reliable detection.
- A glassbreak simulator can be used during installation to verify coverage.
Technical Drawing
