Risco Wireless Panda Keypad with Inbuilt Proximity Reader - Suits WiComm Pro & Agility4 - White
Key Features
- Two way wireless keypad for Risco systems.
- Integrated proximity reader for credential based arming and disarming.
- Real time system status, alarm and trouble indications.
- Responsive tactile keys for reliable operation.
- Wall and cover tamper protection.
- Wireless installation with mounting bracket and single screw fixation.
- Flush mount accessory available for discreet installation.
- Suitable for residential and small commercial installations.
Specifications
- Item Code: RW332KPP400D
- Product Type: Wireless keypad with proximity reader
- Wireless Communication: Bi-directional
- System Compatibility: Agility4, WiComm, WiComm Pro
- Wireless Frequency: 433.92 megahertz
- Proximity Frequency: 13.56 megahertz
- Power Supply: 4 × CR123 3 volt lithium batteries
- Typical Battery Life: 3 years
- Standby Current: 9 microamps
- Maximum Current: 150 milliamps
- Operating Temperature: -10°C to 55°C
- Storage Temperature: -20°C to 70°C
- Finish: White
What's In The Box
- Risco wireless Panda keypad with proximity reader
- Mounting bracket
- 4 × CR123 lithium batteries
- Installation instructions
Suitable Uses
- Wireless Agility4 or WiComm Pro alarm installations.
- Residential or small commercial security systems.
- Retrofit installations where wiring is difficult.
- Entry and exit control using proximity credentials.
Dimensions
| Height | Width | Depth |
|---|---|---|
| 178 mm | 103 mm | 38 mm |
PDF Resources
|
Risco Panda Wireless Keypad with Proximity Installer Guide |
Frequently Asked Questions
- Does this keypad require wiring to the control panel?
No. It communicates wirelessly with compatible Risco systems. - Can it be used with LightSYS+ systems?
No. This model is designed for Agility4 and WiComm series systems. - Are batteries included?
Yes. Four CR123 lithium batteries are supplied with the keypad.
Additional Information
- Wireless keypads are commonly specified in retrofit installations where running bus cable is difficult.
- Two way wireless communication allows real time feedback from the control panel.
- Flush mounting accessories are available where a lower profile installation is required.
Technical Drawing
