Risco Wireless Indoor Curtain PIR Detector – with 90 Degree Bracket – White
The Risco wireless indoor curtain passive infrared detector is designed to protect windows and large glass doors in residential and commercial environments. Its narrow curtain detection pattern provides focused coverage along openings, while sunlight protection technology helps reduce false alarms.
Key Features
- Wireless indoor curtain passive infrared detector.
- Selectable coverage range of 3 metres or 6 metres.
- Designed for window and glass door protection.
- Sunlight protection technology helps reduce false alarms from bright light sources.
- True temperature compensation for stable performance.
- Easy battery replacement for end users.
- Includes 90 degree bracket for left or right side mounting.
- Compatible with Risco one-way and two-way wireless systems.
Specifications
- Item Code: RWX106402002
- Detector Type: Indoor curtain passive infrared detector
- Wireless Connectivity: Yes
- Finish: White
- Coverage Range: Selectable 3 metres or 6 metres
- Mounting Height: 1.8 to 3 metres
- Frequency: 433.92 megahertz
- Battery Type: 1 × CR123 3 Volt lithium battery
- Typical Battery Life: 3 years
- Current Consumption: 8 microamp standby
- Supervision Transmission: 0 to 255 minutes
- Operating Temperature: −10°C to 40°C
- Storage Temperature: −20°C to 60°C
- Dimensions: 98.5 × 31.5 × 35 millimetres
What's In The Box
- 1 × Risco wireless curtain PIR detector
- 1 × 90 degree mounting bracket
- 1 × CR123 lithium battery
Suitable Uses
- Protecting windows and sliding glass doors.
- Residential perimeter protection.
- Commercial shopfront or office window protection.
- Installations requiring focused curtain detection.
Dimensions
| Height | 98.5 mm |
| Width | 31.5 mm |
| Depth | 35 mm |
Frequently Asked Questions
- What is a curtain detector used for?
Curtain detectors create a narrow detection zone, typically used to protect windows, doors or specific passageways. - Can the coverage range be adjusted?
Yes. The detector offers selectable coverage ranges of 3 metres or 6 metres. - Is the battery included?
Yes. A CR123 lithium battery is supplied with the detector.
Additional Information
- Curtain detectors are commonly used as perimeter protection along windows and sliding doors.
- They are often specified where full room coverage is not required.
- Correct mounting height and alignment are important for accurate detection.
