Risco WatchIN Grade 3 Dual Tech Indoor Detector – Anti-Mask – Relay and Bus – 25m Range
The Risco WatchIN Grade 3 detector is a dual technology indoor motion detector designed for harsh commercial and industrial environments. It combines passive infrared and microwave technologies with anti-mask protection to deliver reliable detection and strong immunity to false alarms.
Key Features
- Grade 3 dual technology detector combining passive infrared and microwave sensing.
- 25 metre wide-angle coverage for large internal spaces.
- Anti-mask protection using active infrared technology.
- Anti-cloak and sway recognition technologies to reduce false alarms.
- Relay and bus connectivity options.
- Direct light immunity and robust industrial design.
- IP65 environmental rating for dust and humidity resistance.
- Includes swivel mounting bracket.
Specifications
- Item Code: RK325DT0000D
- Detector Type: Dual technology indoor motion detector
- Security Grade: Grade 3
- Coverage Range: 25 metres wide angle
- Connectivity: Relay and bus
- Voltage Requirements: 9–16 Volt direct current
- Current Consumption (Relay Mode): 45 milliamp standby, 60 milliamp maximum
- Current Consumption (Bus Mode): 30 milliamp standby, 45 milliamp maximum
- Alarm Contacts: 30 Volt direct current, 1 Amp
- Anti-Mask Contacts: 24 Volt direct current, 0.1 Amp
- Radio Frequency Immunity: 10 Volt per metre (80 MHz to 2.7 GHz)
- Operating Temperature: −10°C to 55°C
- Storage Temperature: −20°C to 60°C
- Environmental Rating: IP65
- Dimensions: 215 × 95 × 85 millimetres
- Weight: 0.632 kilograms
What's In The Box
- 1 × Risco WatchIN Grade 3 dual technology detector
- 1 × Swivel mounting bracket
Suitable Uses
- Industrial production areas.
- Warehouses and storage facilities.
- Construction sites and temporary structures.
- Shopping centres and large commercial interiors.
- Aircraft hangars and high-ceiling spaces.
Dimensions
| Height | 215 mm |
| Width | 95 mm |
| Depth | 85 mm |
| Weight | 0.632 kg |
Frequently Asked Questions
- Is this detector suitable for harsh environments?
Yes. It is designed for industrial environments and carries an IP65 rating for resistance to dust and humidity. - Does this detector support both relay and bus connections?
Yes. It supports both relay and bus connectivity for flexible installation options. - Does the detector include a mounting bracket?
Yes. A swivel bracket is included for adjustable installation.
Additional Information
- Grade 3 detectors are commonly specified in higher-risk commercial and industrial sites.
- Dual technology sensing helps reduce false alarms in challenging environments.
- Anti-mask protection is often required in monitored or high-security installations.
