Risco Vitron Plus Grade 3 Acoustic Glass Break Detector - 9m Coverage - White
Key Features
- Grade 3 acoustic glass break detector for high security applications.
- 9 metre coverage radius using omni-directional microphone.
- Microprocessor-based dual frequency pattern recognition.
- Detects plate, tempered, laminated and wired glass types.
- Adjustment-free design for simple installation.
- High immunity to false alarms from non-glass noises.
- Wall, ceiling or flush mounting options.
- Dead microphone supervision for reliability.
- Remote test capability without opening the unit.
Specifications
- Item Code: RG71FM0G300B
- Product Type: Acoustic Glass Break Detector
- Grade: Grade 3
- Coverage: Up to 9 metres
- Detection Method: Dual frequency acoustic pattern recognition
- Mounting: Wall, ceiling or flush mount
- Glass Types: Plate, tempered, laminated and wired glass
- Microphone: Omni-directional with supervision
- Finish: White
What's In The Box
- 1 × Risco Vitron Plus acoustic glass break detector
- Mounting hardware
- Installation instructions
Suitable Uses
- Commercial premises requiring Grade 3 security protection.
- Retail shopfront glazing and display windows.
- Office and industrial perimeter glass protection.
- High risk residential or commercial sites.
- Installations where glass break detection is required instead of contacts.
Download PDF Resources
|
Vitron Plus Acoustic Glass Break Detector Installation Manual |
Frequently Asked Questions
- Can this detector be used on all types of glass?
Yes. It is designed to detect breakage of plate, tempered, laminated and wired glass in framed installations. - Where should this detector be mounted?
It can be mounted on a wall, ceiling or flush mounted, provided it has a clear acoustic path to the protected glass within the 9 metre coverage area. - What is a common installation mistake to avoid?
Installing the detector too far from the glass or behind heavy curtains or partitions can reduce detection reliability.
Additional Information
- Commonly specified in Australian commercial sites where Grade 3 intrusion detection is required.
- Acoustic detectors are often preferred for large glazed areas where multiple contacts would otherwise be required.
- Detector performance depends on correct positioning and room acoustics.
- Heavy drapes, acoustic panels or partitions between the detector and glass can reduce effectiveness.
- Professional installers typically test the unit using a dedicated Vitron tester after installation.
