Risco RP432KP0000A Standard Graphic LCD Keypad – Suits LightSYS+ and LightSYS2
The Risco RP432KP0000A is a standard graphic LCD keypad designed for use with the Risco LightSYS+ and LightSYS2 intrusion alarm platforms. It provides clear system status display and reliable everyday arming and disarming control through the Risco 4-wire BUS.
This keypad is commonly specified in Australian residential and commercial alarm installations where a durable, panel-mounted user interface is required.
Key Features
- Standard graphic LCD keypad for LightSYS+ and LightSYS2 alarm systems.
- Connects via 4-wire BUS to the main control panel.
- Supports installation up to 300 metres from the main panel.
- Available in versions with or without proximity reader functionality.
- Certified to EN 50131-3 Grade 2 Class II.
- Designed for professional security system installations.
Specifications
- Item Code: RP432KP0000A
- Brand: Risco
- Module Type: Standard LCD keypad
- Compatible Systems: LightSYS+, LightSYS2, ProSYS panels
- Main Panel Connection: 4-wire BUS
- Maximum BUS Distance: Up to 300 metres from main panel
- Typical Current Consumption: 48 milliampere at 13.8 Volt Direct Current
- Maximum Current Consumption: 52 milliampere
- Operating Temperature: -10 to 55 degrees Celsius
- Storage Temperature: -20 to 60 degrees Celsius
- Compliance: EN 50131-3 Grade 2 Class II
- Dimensions: 153 millimetre x 84 millimetre x 28 millimetre
What's In The Box
- 1 × Risco RP432KP0000A LCD keypad
- Mounting base and enclosure fittings
- Installer documentation (downloadable)
Suitable Uses
- Residential and commercial LightSYS+ alarm installations.
- Sites requiring a standard keypad for daily system control.
- Security upgrade projects using LightSYS2 or ProSYS platforms.
- Installations where BUS-mounted keypads are located remotely from the panel.
Dimensions
Risco LightSYS LCD Keypads – Item Code Family
Download PDF Resources
Frequently Asked Questions
- Does this keypad include a proximity card reader?
No. RP432KP0000A is the standard keypad version. The KPP model includes proximity reader functionality. - How far can the keypad be installed from the alarm panel?
It can be installed up to 300 metres from the main panel when correctly wired on the BUS. - What is a common installation mistake to avoid?
Incorrect BUS wiring polarity or duplicate BUS addressing can prevent the keypad from communicating properly.
Additional Information
- This keypad is widely used in Australian alarm installs because it provides a reliable, simple interface without requiring credential management.
- BUS addressing must be set correctly during commissioning, especially on multi-keypad sites.
- If upgrading from older LightSYS keypads, confirm panel firmware compatibility before replacement.
Technical Drawing
.
