Risco RK66S000000B Seismic Detector – Relay and BUS Connectivity – White
The Risco RK66S000000B Seismic Detector is a high security vibration and temperature monitoring device designed for 24 hour protection of safes, vaults, ATMs, reinforced concrete walls, strong rooms and steel enclosures.
Using advanced piezo sensing and digital signal processing with pattern recognition, the detector identifies intrusion methods including sledge hammer attacks, diamond head drilling, hydraulic pressure tools, explosives and thermal attacks.
The unit supports both RISCO BUS connectivity for remote configuration and diagnostics, or conventional relay connection with built-in end of line resistors.
Key Features
- Piezo sensor with digital signal processing and pattern recognition.
- Monitors vibration and temperature of protected surfaces.
- Detection radius up to 5 metre.
- Selectable installation as relay detector or RISCO BUS device.
- Remote parameter setting and diagnostics via RISCO BUS.
- Adjustable vibration sensitivity with 8 selectable levels.
- Selectable explosion and sledge hammer detection.
- Built-in end of line resistors.
- Wall and cover tamper protection.
- Anti-drilling shield included as standard.
Specifications
- Item Code: RK66S000000B
- Detector Type: Seismic vibration detector
- Connectivity: Relay output or RISCO BUS (RS485)
- Detection Coverage: Up to 5 metre radius
- Operating Voltage: 9 to 16 Volt Direct Current
- Current Consumption: Typically 20 milliampere at 12 Volt Direct Current
- Alarm Contacts: 24 Volt Direct Current, 0.1 Ampere Form C changeover relay
- Tamper Contacts: 24 Volt Direct Current, 0.1 Ampere
- Alarm Hold Time: 2.5 seconds
- Ingress Protection: IP43
- Impact Rating: IK08
- Operating Temperature: -40 to 70 degrees Celsius
- Dimensions: 102 millimetre length x 80.2 millimetre width x 27.5 millimetre height
- Weight: 220 gram
- Finish: White
What's In The Box
- 1 × RK66S Seismic Detector
- Metal mounting plate
- Internal and external test generator
- Anti-drilling shield
- Heavy duty installation bolts
Suitable Uses
- Safes and vault protection.
- ATM and vending machine security.
- Strong rooms and reinforced concrete walls.
- Steel armoured cabinets and secure enclosures.
Dimensions
Download PDF Resources
Frequently Asked Questions
- Can this detector be connected directly to the RISCO BUS?
Yes. It supports BUS connectivity for remote configuration and diagnostics, or can be wired as a conventional relay detector. - What surfaces can it protect?
It is suitable for safes, vaults, reinforced concrete walls, steel cabinets, ATMs and similar structures. - Is sensitivity adjustable?
Yes. Sensitivity and detection parameters are adjustable via dip switches or remotely when connected to the BUS.
Additional Information
- Commonly specified in banking, cash handling and high value storage environments.
- Remote sensitivity reduction input allows temporary adjustment during ATM or vending dispensing.
- Correct mounting to solid substrate is critical to achieve full 5 metre detection radius.
