Risco 2-Way Wireless Repeater – White
The Risco RW132XWR900A 2-Way Wireless Repeater is designed to extend and optimise wireless signal range for RISCO Group alarm systems including WiComm Pro, Agility4, and LightSYS+.
It supports up to 32 two-way wireless zones and helps improve communication reliability in challenging installation environments.
Key Features
- Designed for RISCO WiComm Pro, Agility4 and LightSYS+ alarm systems.
- Optimises and extends wireless range for supported devices.
- Supports up to 32 two-way wireless zones per repeater.
- Up to 4 repeaters can be included per system.
- Supports detectors, camera detectors, sirens, keypads, keyfobs, and IO expanders.
- Does not support one-way wireless devices.
Specifications
- Item Code: RW132XWR900A
- Brand: Risco
- Product Type: 2-Way Wireless Repeater
- Voltage: 10 to 16 Volt AC or DC
- Current: 100 mA (charging, transmission and reception)
- Battery Type: 3.6V Lithium-Ion 18650, 2200 mAh
- Battery Backup: Greater than 12 hours
- Operating Temperature: -10°C to 55°C
- Dimensions: 130 x 75 x 25 mm
- Weight: 0.2 kg
- Frequency: 433.92 / 916 MHz
- Finish: White
- Wireless Connectivity: Yes
What’s In The Box
- 1 × Risco 2-Way Wireless Repeater Module
- Internal rechargeable battery
- Installation instructions (PDF)
Suitable Uses
- Extending wireless range in large homes or commercial buildings.
- Improving wireless signal stability in difficult installation conditions.
- Supporting multiple two-way wireless detectors and accessories.
PDF Resources
Frequently Asked Questions
- Which alarm panels does this repeater suit?
It is designed for RISCO WiComm Pro, Agility4, and LightSYS+ systems. - How many repeaters can be installed on one system?
A maximum of 4 repeaters can be included per system. - Does it work with one-way wireless devices?
No. This repeater supports two-way wireless devices only.
Additional Information
- Wireless repeaters are ideal for expanding system coverage without extra cabling.
- Placement should be chosen to maximise wireless signal strength between devices and the panel.
- Installation should be performed by a qualified security technician.
Technical Drawing
