Raven RP82 Threshold Plate - Clear Anodised
The Raven RP82 is a low profile aluminium threshold plate designed for installation at the door sill. It is commonly used in conjunction with Raven automatic door bottom seals to reduce rain, draughts, noise and smoke infiltration.
Its slim profile supports compliance with accessibility requirements when installed correctly and is widely specified across Australian commercial and public access buildings.
Key Features
- Low profile threshold plate for door sills
- Designed to work with Raven door bottom seals
- Helps reduce rain, draught, noise and smoke infiltration
- Suitable for fire rated door assemblies when installed as tested
- Stock lengths supplied for site cutting where required
Compatibility
- Location: Door sill
- Used with Raven automatic bottom seals and drop seals
- Suitable for timber and metal door applications
- May be screw fixed or adhesive fixed depending on project requirements
Full Specifications
| Brand | Raven |
| Product Code | RP82 |
| Primary Item Code | RP82X1000CA |
| Door Seal Type | Threshold Plate |
| Material | Anodised aluminium 25 micron |
| Finish | Clear Anodised |
| Profile Size | 5 mm x 40 mm |
| Overall Length (This model) | 1000 mm |
| Fixing | Screw fix or builders adhesive. Colour matched zinc plated cross recess head countersunk self tapping screws supplied. |
| Fire Rated | Yes when used in approved fire door assemblies |
All available variants included:
- RP82X1000CA: 5 mm x 40 mm x 1000 mm
- RP82X2000CA: 5 mm x 40 mm x 2000 mm
Available Finish Color
Whats in the Box
- 1 x Raven RP82 threshold plate (stock length)
- Colour matched zinc plated fixing screws
Dimension
| Item Code | Profile | Length |
|---|---|---|
| RP82X1000CA This model |
5 mm x 40 mm | 1000 mm |
| RP82X2000CA | 5 mm x 40 mm | 2000 mm |
Frequently Asked Questions
- Is this threshold plate fire rated?
Yes, it is approved for use in fire door assemblies when installed in accordance with tested configurations including AS1530.4 and AS/NZS 1905.1. - Can this be used in accessible doorways?
Yes, the low profile design assists compliance with NCC and AS1428.1 when installed correctly. - Can I glue it instead of screw fixing?
Builders adhesive may be used for concealed fixing where appropriate, subject to project requirements.
Additional Information
- Commonly specified in commercial, healthcare and education projects to improve acoustic and smoke control at the door sill.
- For best results, pair with a compatible Raven automatic bottom seal to achieve a continuous perimeter seal.
- When installed on fire doors, ensure all components including the bottom seal are tested together as an assembly.
