Raven RP78Si Perimeter Seal with Gaskets - Clear Anodised
The Raven RP78Si is an acoustic medium temperature smoke door frame seal designed for installation onto door stops at the head and jambs. It features a sturdy aluminium carrier with slotted adjustment and concealed fixings, allowing installation without removing the door.
Commonly specified in Australian commercial projects, the RP78Si supports acoustic performance, smoke containment and fire compliance when installed in approved assemblies.
Key Features
- Acoustic and medium temperature smoke frame seal
- Adjustable slotted aluminium carrier
- Concealed screw fixing with cover strip
- Can be mitred or butt jointed
- Install without removing the door
- Suits perimeter gaps from 0 mm to 6 mm
Compatibility
- Location: Head and jambs of single and double butt hinged doors
- Designed for installation onto door stops
- Compatible with Raven RP8Si, RP16Si, RP35Si, RP38Si, RP99Si, RP126Si, RP127Si and RP128Si automatic bottom seals
Full Specifications
| Brand | Raven |
| Product Code | RP78Si |
| Primary Item Code | RP78SIX1000CA |
| Seal Type | Frame Seal |
| Seal Insert | RP394Si grey or light grey silicon rubber (SE) |
| Finish | Clear Anodised Aluminium (15 micron) |
| Gap Range | 0 mm to 6 mm |
| Fixing | Concealed screw fixing. Zinc plated cross recess head self tapping screws and cover strip supplied. |
| Fire Rated | Yes |
| Door Seal Set | Individual Seal |
All available length variants (included as required):
- RP78SIX1000CA: 1000 mm
- RP78SIX1250CA: 1250 mm
- RP78SIX1500CA: 1500 mm
- RP78SIX2000CA: 2000 mm
- RP78SIX2250CA: 2250 mm
- RP78SIX2500CA: 2500 mm
Whats in the Box
- 1 x RP78Si aluminium carrier
- RP394Si silicon gasket pre inserted
- Concealed fixing screws
- Cover strip
Dimension
| Item Code | Length |
|---|---|
| RP78SIX1000CA This model |
1000 mm |
| RP78SIX1250CA | 1250 mm |
| RP78SIX1500CA | 1500 mm |
| RP78SIX2000CA | 2000 mm |
| RP78SIX2250CA | 2250 mm |
| RP78SIX2500CA | 2500 mm |
Item Code Family
| Product | Item Code | Configuration / Size |
|---|---|---|
| Raven RP78Si Single Door Set Perimeter Seal with Gaskets - Black This model |
RP78SILSDSCA | 1 x 1000 mm and 2 x 2750 mm |
| Raven RP78Si Single Door Set Perimeter Seal with Gaskets - Black | RP78SISDSCA | 1 x 1000 mm and 2 x 2100 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX1000CA | 1000 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX1250CA | 1250 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX1500CA | 1500 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX2000CA | 2000 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX2250CA | 2250 mm |
| Raven RP78Si Perimeter Seal with Gaskets - Black (Stock Length) | RP78SIX2500CA | 2500 mm |
Frequently Asked Questions
- Is RP78Si suitable for fire doors?
Yes. It is approved for use in fire door assemblies when installed in accordance with AS1530.4 and AS/NZS 1905.1 test requirements. - Can this be installed without removing the door?
Yes. The design allows installation around the jamb and head without removing the door leaf. - What gap does this seal accommodate?
It is designed to seal gaps between 0 millimetres and 6 millimetres.
Additional Information
- Commonly specified in Australian commercial and institutional buildings for acoustic and smoke performance.
- Best performance is achieved when used together with a compatible Raven automatic bottom seal.
- Mitred corners provide a cleaner finish, while butt joints allow faster on-site installation.
